JIANGSU CHANGJIANG ELECTRONICS TECHNOLOGY CO., LTD
SOD-323 Plastic-Encapsulate
Diode
BAV16WS/1N4148WS
FAST SWITCHING DIODE
SOD-323
Features
1.00
路
路
路
路
Fast Switching Speed
Surface Mount Package Ideally Suited for
Automatic Insertion
For General Purpose Switching Applications
High Conductance
1.30
1.70
Marking: T4
2.65
Unit:mm
Maximum Ratings
@ T
A
= 25擄C unless otherwise specified
Characteristic
Non-Repetitive Peak Reverse Voltage
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Forward Continuous Current (Note 1)
Average Rectified Output Current (Note 1)
Non-Repetitive Peak Forward Surge Current @ t = 1.0ms
@ t = 1.0s
Power Dissipation (Note 1)
Thermal Resistance Junction to Ambient Air (Note 1)
Operating and Storage Temperature Range
Symbol
V
RM
V
RRM
V
RWM
V
R
V
R(RMS)
I
FM
I
O
I
FSM
P
d
R
qJA
T
j
, T
STG
Value
100
75
53
300
150
2.0
1.0
200
625
-65 to +150
Unit
V
V
V
mA
mA
A
mW
K/W
擄C
Electrical Characteristics
Characteristic
Maximum Forward Voltage
@ T
A
= 25擄C unless otherwise specified
Symbol
V
FM
Min
戮
Max
0.715
0.855
1.0
1.25
1.0
50
30
25
2.0
4.0
Unit
Test Condition
I
F
= 1.0mA
I
F
= 10mA
I
F
= 50mA
I
F
= 150mA
V
R
= 75V
V
R
= 75V, T
j
= 150擄C
V
R
= 25V, T
j
= 150擄C
V
R
= 20V
V
R
= 0, f = 1.0MHz
I
F
= I
R
= 10mA,
I
rr
= 0.1 x I
R
, R
L
= 100W
V
mA
mA
mA
nA
pF
ns
Maximum Peak Reverse Current
Junction Capacitance
Reverse Recovery Time
I
RM
C
j
t
rr
戮
戮
戮
Notes:
1. Valid provided that terminals are kept at ambient temperature.
0.30
1 /2
1
2
3
