BAS40T/-04T/-05T/-06T
SURFACE MOUNT SCHOTTKY BARRIER DIODE
Features
NEW PRODUCT
路
路
路
路
Low Forward Voltage Drop
Fast Switching
Ultra-Small Surface Mount Package
PN Junction Guard Ring for Transient and ESD
Protection
Case: SOT-523, Molded Plastic
Case material - UL Flammability Rating 94V-0
Moisture sensitivity: Level 1 per J-STD-020A
Terminals: Solderable per MIL-STD-202, Method
208
Polarity: See Diagrams Below
Marking: See Diagrams Below (& Page 2)
Weight: 0.002 grams (approx.)
Ordering Information, see Page 2
B
SOT-523
Dim
A
C
TOP VIEW
E
G
H
K
M
B C
Min
0.15
0.75
1.45
戮
0.90
1.50
0.00
0.60
0.10
0.10
0.45
0擄
Max
0.30
0.85
1.75
戮
1.10
1.70
0.10
0.80
0.30
0.20
0.65
8擄
Typ
0.22
0.80
1.60
0.50
1.00
1.60
0.05
0.75
0.22
0.12
0.50
戮
A
B
C
D
G
H
J
N
Mechanical Data
路
路
路
路
路
路
路
路
K
L
M
N
a
J
D
L
All Dimensions in mm
BAS40T Marking: 43
BAS40-04T Marking: 44
BAS40-05T Marking: 45
BAS40-06T Marking: 46
Maximum Ratings
@ T
A
= 25擄C unless otherwise specified
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Forward Continuous Current (Note 1)
Non-Repetitive Peak Forward Surge Current
Power Dissipation (Note 1)
Thermal Resistance Junction to Ambient (Note 1)
Operating Temperature Range
Storage Temperature Range
@ t = 1.0s
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
FM
I
FSM
P
d
R
qJA
T
j
T
STG
Value
40
28
200
600
150
833
-55 to +125
-65 to +150
Unit
V
V
mA
mA
mW
擄C/W
擄C
擄C
Electrical Characteristics
@ T
A
= 25擄C unless otherwise specified
Characteristic
Reverse Breakdown Voltage (Note 2)
Forward Voltage (Note 2)
Leakage Current (Note 2)
Total Capacitance
Reverse Recovery Time
Notes:
Symbol
V
(BR)R
V
F
I
R
C
T
t
rr
Min
40
戮
戮
戮
戮
Max
戮
380
1000
200
5.0
5.0
Unit
V
mV
mV
nA
pF
ns
Test Condition
I
R
= 10mA
I
F
= 1.0mA, t
p
< 300ms
I
F
= 40mA, t
p
< 300ms
V
R
= 30V
V
R
= 0, f = 1.0MHz
I
F
= I
R
= 10mA,
I
rr
= 0.1 x I
R
, R
L
= 100W
1. Device mounted on FR-4 PC board with recommended pad layout, which can be found on our website at
http://www.diodes.com/datasheets/ap02001.pdf.
2. Short duration test pulse used to minimize self-heating effect.
DS30265 Rev. 5 - 2
1 of 2
BAS40T/-04T/-05T/-06T
1
2
