BA7649 Datasheet

  • BA7649

  • Video signal switcher

  • 5頁

  • ROHM

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Multimedia ICs
Video signal switcher
BA7649A / BA7649AF
The BA7649A and BA7649AF are five-channel analog multiplexers (the IN5 pin can be used a mute input) designed
for use in video cassette recorders. They feature large dynamic range, and wide operating frequency range, and
have sync-tip inputs which are ideal for switching video signals.
鈥?/div>
Applications recorders and televisions
Video cassette
鈥?/div>
Features/ 1-output switches.
1) 5-input
2) Built-in mute (the IN5 pin can be use a mute input).
3) Sync-tip clamp inputs.
4) Wide operating supply voltage range
(4.5V to 13.0V).
5) Low power consumption (48mW Typ.).
6) Excellent frequency characteristics
(10MHz, 0dB Typ.).
7) Wide dynamic range (3.5V
P-P
Typ.).
8) Low interchannel crosstalk
( 鈥?65dB Typ., f = 4.43MHz).
9) DIP / SOP 14 pin package.
鈥?/div>
Absolute maximum ratings (Ta = 25擄C)
BA7649A
Parameter
Power supply voltage
Allowable current
Operating temperature
Storage temperature
Symbol
V
CC
Pd
Topr
Tstg
Limits
13.5
1100
鈭?/div>
鈥?25 ~ + 75
鈥?55 ~ + 125
Unit
V
mW
擄C
擄C
鈭?/div>
Reduced by 11.0mW for each increase in Ta of 1擄C over 25擄C.
BA7649AF
Parameter
Power supply voltage
Allowable current
Operating temperature
Storage temperature
Symbol
V
CC
Pd
Topr
Tstg
Limits
13.5
450
鈭?/div>
鈥?25 ~ + 75
鈥?55 ~ + 125
Unit
V
mW
擄C
擄C
鈭?/div>
Reduced by 4.5mW for each increase in Ta of 1擄C over 25擄C when mounted on a 50mm
脳
50mm PCB board.
1
