BA7606F Datasheet

  • BA7606F

  • Video signal switcher

  • 85.02KB

  • 6頁

  • ROHM

掃碼查看芯片數據手冊

上傳產品規(guī)格書

PDF預覽

Multimedia ICs
Video signal switcher
BA7606 / BA7606F
The BA7606 and BA7606F are switching ICs developed for use in video cameras. Each contains three two-chan-
nelanalog multiplexers. They feature a large dynamic range, and wide operating freqency range, and the switches
have pedestal clamp inputs which are ideal for switching RGB and video signals.
鈥?/div>
Applications recorders and televisions
Video cassette
鈥?/div>
Features / 1-output switches.
1) Three 2-input
2) 5V power supply.
3) Pedestal clamp inputs
4) Low power consumption (62.5mW Typ.).
5) Excellent frequency characteristics
(10MHz, 鈥?1dB Typ.).
6) Wide dynamic range (2.6Vp-p Typ.).
7) Fast switching speed (50ns Typ.).
鈥?/div>
Block diagram
IN2a 1
CTLa 2
OUTa
3
S
b
S
a
16 IN1a
15 GND
14 IN2b
13 V
CC
12 CTLb
11 IN1b
S
C
10
9
CLAMP
PULSE
IN1c
GND 4
OUTb 5
OUTc 6
CTLc 7
IN2c 8
CTL
L
H
Output
IN2
IN1
S
a
, S
b
, S
c
:
pedestal-clamped input
鈥?/div>
Absolute maximum ratings (Ta = 25擄C)
Parameter
Power supply voltage
Power dissipation
Operating temperature
Storage temperature
Symbol
V
CC
Pd
Topr
Tstg
Limits
9
500
鈭?/div>
鈥?40 ~ + 85
鈥?55 ~ + 125
Unit
V
mW
擄C
擄C
鈭?/div>
Reduced by 5.0mW for each increase in Ta of 1擄C over 25擄C.
1
