Bay Linear
Inspire the Linear Power
300 mA CMOS Low Dropout LDO
Description
The B4300 series are a group of positive output voltage,
three-pin regulators, which provide a high current even
when the input/output voltage differential is small. Low
power consumption and high accuracy is achieved
though CMOS and programmable fuse technologies.
Output voltage: 2.0V to 6.0V in 0.1V increments.
The B4300 consists of a high-precision voltage
reference, an error correction circuit, and a current
limited output driver.
Available in SOT-89 (300mW), and SOT-223 (500mW)
packages minimizing the usage of board real state.
B4300
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Maximum output current: 300 mA.
Highly accurate: Output voltage +/- 1.4%
Extremely Low Ground Current 6碌A(chǔ)
CMOS low power consumption.
Over-Current & Over-Temp. Protection
Small input/output differential:
0.3V @ 300mA
0.1V @ 100mA
Pin-to-Pin replacement for TC1108 & XC6203
Offered in SOT-89 & SOT-223
Applications
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Battery Powered Equipment
Notebook PC, Palmtops, PDA
Portable Cameras and Video Recorders
Reference Voltage Sources
Pin Connection
Ordering Information
Package
SOT-89
SOT-223
Part No.
B4300CR-X.X
B4300CN-X.X
X.X = Fixed Output Voltages from 2.0V to 6.0V
SOT-223 (N)
Vin
2
1
Vss
2
3
SOT-89 (R)
Vin
2
1
Vss
2
Vin
3
Vout
Vin Vout
Top View
Top View
Bay Linear, Inc
2478 Armstrong Street, Livermore, CA 94550 Tel: (925) 989-7144, Fax: (925) 940-9556
www.baylinear.com
