AVS10
AUTOMATIC VOLTAGE SWITCH (SMPS < 300W)
CONTROLLER
s
s
s
s
s
50/60Hz FULL COMPATIBILITY
INTEGRATED VOLTAGE REGULATOR
TRIGGERING PULSE TRAIN OF THE TRIAC
PARASITIC FILTER
LOW POWER CONSUMPTION
TRIAC
s
s
s
s
s
HIGH EFFICIENCY AND SAFETY SWITCHING
UNINSULATED PACKAGE : AVS10CB
INSULATED PACKAGE 2500V
(RMS
) : AVS10CBI
V
DRM
=
鹵
600V
I
T(RMS)
: 8A
A1
A2
G
P
DIP8
(Plastic)
B
TO 220AB
(Plastic)
DESCRIPTION
The AVS10 kit is an automatic mains selector
(110/220V AC) to be used in SMPS < 300 W. It
is composed of 2 devices :
鈥?/div>
The
Controller
is optimized for low consump-
tion and high security triggering of the triac.
When connected to V
SS
, the
mode
input acti-
vates an additional
option.
If the main power
drops from 220V to 110V, the triac control re-
mains locked to the 220V mode and avoids
any high voltage spike when the voltage is re-
stored to 220V.
When connected to V
DD
, the
mode
input de-
sactivates this
option.
鈥?/div>
The TRIAC is specially designed for this appli-
cation. An optimization between sensitivity and
dynamic parameters of the triac gate highly
reduces the losses of supply resistor and al-
lows excellent immunity against disturbances.
