AVPRO5001 Datasheet

  • AVPRO5001

  • Quad A/V Drivers

  • 8頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

AVPro
廬
5001
Quad A/V Drivers
Advanced Information
September 1999
DESCRIPTION
The AVPro 5001 device is an audio/video driver IC
that supports four video inputs and two audio inputs.
Each video paths has a gain of 2 with output buffers
designed to drive a 137 ohm load. Each audio path
has two output drivers that are buffered to provide 2
Vrms output (3.2 Vrms maximum). In addition, the
audio drivers use +/- 5 volt power supplies so that
the output is centered around ground. This allows
direct coupling of the 5001 audio outputs to the
associated load. Typical applications for the 5001
include DVD players, VCRs, and digital receivers for
satellite, cable, and terrestrial television.
FEATURES
鈥?/div>
Video section
- Internal DC restore circuits
- 150 ohm drivers
鈥?/div>
Audio section
- better than 90 dB SNR+distortion
- direct coupled outputs
鈥?/div>
+5V and -5V power supplies
鈥?/div>
24-lead small outline (SO) package
BLOCK DIAGRAM
Tgen
Vid1
Osc
VCCv
Vid1_out
DCR
Vid2
DCR
Vid3
DCR
Vid4
DCR
RRef
Cbyp
Mode
VEEv
Aud1
Aud2
GNDa
GNDv
Aud1_out1
Aud1_out2
VCCa
Aud2_out1
Aud2_out2
VEEa
Vid4_out
Vid3_out
Vid2_out
Ref
Gen
