ATV750B(L) Datasheet

  • ATV750B(L)

  • ATV750B(L) [Updated 8/01. 19 Pages] 750 gate high-speed CPLD...

  • 19頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Features
鈥?/div>
Advanced, High-speed Programmable Logic Device 鈥?Superset of 22V10
鈥?Improved Performance - 7.5 ns t
PD
, 95 MHz External Operation
鈥?Enhanced Logic Flexibility
鈥?Backward Compatible with ATV750(L) Software and Hardware
鈥?/div>
New Flip-flop Features
鈥?D- or T-type
鈥?Product Term or Direct Input Pin Clocking
鈥?/div>
High-speed Erasable Programmable Logic Devices
鈥?7.5 ns Maximum Pin-to-pin Delay
Device
ATV750B
ATV750BL
I
CC
, Standby
125 mA
15 mA
鈥?/div>
Highest Density Programmable Logic Available in a 24-pin Package
鈥?/div>
Increased Logic Flexibility
鈥?42 Array Inputs, 20 Sum Terms and 20 Flip-flops
鈥?/div>
Enhanced Output Logic Flexibility
鈥?All 20 Flip-flops Feed Back Internally
鈥?10 Flip-flops are Also Available as Outputs
鈥?/div>
Full Military, Commercial and Industrial Temperature Ranges
High-speed UV
Erasable
Programmable
Logic Device
ATV750B
ATV750BL
Commercial and
industrial versions
are obsolete. Please
use ATF750C.
Military versions
continue to be available,
but please do not
use for new designs.
For new military
applications, recommend
multiple ATF22V10s.
Logic Diagram
Description
The ATV750B(L) is twice as powerful as most other 24-pin programmable logic
devices. Increased product terms, sum terms, flip-flops and output logic configurations
translate into more usable gates. High-speed logic and uniform, predictable delays
guarantee fast in-system performance.
DIP/SOIC
CLK/IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
GND
1
2
3
4
5
6
7
8
9
10
11
12
24
23
22
21
20
19
18
17
16
15
14
13
VCC
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
IN
Pin Name
CLK
IN
I/O
*
V
CC
Function
Clock
Logic Inputs
Bi-directional Buffers
No Internal Connection
+5V Supply
4
3
2
1
28
27
26
IN
IN
CLK/IN
*
VCC
I/O
I/O
IN
IN
GND
*
IN
I/O
I/O
12
13
14
15
16
17
18
IN
IN
IN
*
IN
IN
IN
5
6
7
8
9
10
11
25
24
23
22
21
20
19
I/O
I/O
I/O
*
I/O
I/O
I/O
Pin Configurations
PLCC/LCC
Rev. 0301I鈥?8/01
1
