ATF-33143 Datasheet

  • ATF-33143

  • SC-70 (SOT-343) Low Noise +33.5 dBm OIP3

  • 18頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Low Noise Pseudomorphic HEMT
in a Surface Mount Plastic Package
Technical Data
ATF-33143
Features
鈥?Low Noise Figure
鈥?Excellent Uniformity in
Product Specifications
鈥?1600 micron Gate Width
鈥?Low Cost Surface Mount
Small Plastic Package
SOT-343 (4 lead SC-70)
鈥?Tape-and-Reel Packaging
Option Available
Surface Mount Package
SOT-343
Description
Agilent鈥檚 ATF-33143 is a high
dynamic range, low noise PHEMT
housed in a 4-lead SC-70 (SOT-343)
surface mount plastic package.
Based on its featured performance,
ATF-33143 is ideal for the first or
second stage of base station LNA
due to the excellent combination
of low noise figure and enhanced
linearity
[1]
. The device is also
suitable for applications in Wire-
less LAN, WLL/RLL, MMDS, and
other systems requiring super low
noise figure with good intercept in
the 450 MHz to 10 GHz frequency
range.
Note:
1. From the same PHEMT FET family, the
smaller geometry ATF-34143 may also
be considered for the higher gain
performance, particularly in the higher
frequency band (1.8 GHz and up).
Pin Connections and
Package Marking
Specifications
1.9 GHz; 4V, 80 mA (Typ.)
鈥?0.5 dB Noise Figure
鈥?15 dB Associated Gain
鈥?22 dBm Output Power at
1 dB Gain Compression
鈥?33.5 dBm Output 3
rd
Order
Intercept
SOURCE
3Px
DRAIN
SOURCE
GATE
Note:
Top View. Package marking
provides orientation and identification.
鈥?P鈥?= Device code
鈥渪鈥?= Date code character. A new
character is assigned for each month, year.
Applications
鈥?Tower Mounted Amplifier,
Low Noise Amplifier and
Driver Amplifier for GSM/
TDMA/CDMA Base Stations
鈥?LNA for Wireless LAN, WLL/
RLL and MMDS Applications
鈥?General Purpose Discrete
PHEMT for other Ultra Low
Noise Applications
