ATAR080-D Datasheet

  • ATAR080-D

  • ATAR080-D [Updated 2/03. 59 Pages] Low-current microcontolle...

  • 932.98KB

  • 59頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Features/Benefits
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Extended Temperature Range for Very High Temperature up to 125擄C
Very Low Power Consumption in Active, Power-down and Sleep Mode
2-Kbyte ROM, 256
麓
4-bit RAM
12 Bi-directional I/Os
Up to 6 External/Internal Interrupt Sources
Multifunction Timer/Counter
Programmable System-clock with Prescaler and Five Different Clock Sources
Wide Supply-voltage Range (1.8 V to 6.5 V)
Very Low Sleep Current (< 1 碌A(chǔ))
Synchronous Serial Interface (2-wire, 3-wire)
Watchdog, POR and Brown-out Function
Voltage Monitoring Inclusive Lo_BAT Detect
Flash Controller ATAM893 Available (SSO20)
Description
The ATAR080-D is a member of Atmel鈥檚 family of 4-bit single-chip microcontrollers. It
contains ROM, RAM, parallel I/O ports, one 8-bit programmable multifunction
timer/counter with modulator function, voltage supervisor, interval timer with watchdog
function and a sophisticated on-chip clock generation with external clock input, inte-
grated RC-, 32-kHz and 4-MHz crystal-oscillators.
Figure 1.
Block Diagram
V SS V DD
NRST/
OSC1 OSC2
Low-current
Microcontroller
for Wireless
Communication
ATAR080-D
Brown-out protect
RESET
Voltage monitor
External input
VMI
External
RC
Crystal
oscillators oscillators clock input
Clock management
UTCM
Timer 1
interval- and
watchdog timer
ROM
2 K x 8 bit
RAM
256 x 4 bit
Timer 2
8/12-bit timer
with modulator
SSI
Serial interface
T2I
T2O
SD
SC
Data direction
BP20/NTE
Port 2
MARC4
4-bit CPU core
BP21
BP22
BP23
I/O bus
Data direction +
alternate function
Port 4
Data direction +
interrupt control
Port 5
BP40
BP42
INT3
T2O BP43
INT3
SC BP41
SD
VMI
T2I
BP50
BP52
INT6
INT1
BP53
BP51
INT1
INT6
Rev. 4676A鈥?BMCU鈥?2/03
1
