AT90PWM2 Datasheet

  • AT90PWM2

  • 8-bit Microcontroller with 8K Bytes In-System Programmable F...

  • 365頁

  • ATMEL   ATMEL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Features
鈥?/div>
High Performance, Low Power AVR 廬 8-bit Microcontroller
鈥?/div>
Advanced RISC Architecture
鈥?Powerful Instructions - Most Single Clock Cycle Execution
鈥?32 x 8 General Purpose Working Registers
鈥?Fully Static Operation
鈥?Up to 1 MIPS throughput per MHz
鈥?On-chip 2-cycle Multiplier
Data and Non-Volatile Program Memory
鈥?8K Bytes Flash of In-System Programmable Program Memory
鈥?Endurance: 10,000 Write/Erase Cycles
鈥?Optional Boot Code Section with Independent Lock Bits
In-System Programming by On-chip Boot Program
True Read-While-Write Operation
鈥?512 Bytes of In-System Programmable EEPROM
鈥?Endurance: 100,000 Write/Erase Cycles
鈥?512 Bytes Internal SRAM
鈥?Programming Lock for Flash Program and EEPROM Data Security
On Chip Debug Interface (debugWIRE)
Peripheral Features
鈥?Two or three 12-bit High Speed PSC (Power Stage Controllers) with 4-bit
Resolution Enhancement
鈥?Non Overlapping Inverted PWM Output Pins With Flexible Dead-Time
鈥?Variable PWM duty Cycle and Frequency
鈥?Synchronous Update of all PWM Registers
鈥?Auto Stop Function for Event Driven PFC Implementation
鈥?Less than 25 Hz Step Width at 150 kHz Output Frequency
鈥?PSC2 with four Output Pins and Output Matrix
鈥?One 8-bit General purpose Timer/Counter with Separate Prescaler and Capture
Mode
鈥?One 16-bit General purpose Timer/Counter with Separate Prescaler, Compare
Mode and Capture Mode
鈥?Programmable Serial USART
鈥?Standard UART mode
鈥?16/17 bit Biphase Mode for DALI Communications
鈥?Master/Slave SPI Serial Interface
鈥?10-bit ADC
鈥?Up To 11 Single Ended Channels and 2 Fully Differential ADC Channel Pairs
鈥?Programmable Gain (5x, 10x, 20x, 40x on Differential Channels)
鈥?Internal Reference Voltage
鈥?10-bit DAC
鈥?Two or three Analog Comparator with Resistor-Array to Adjust Comparison
Voltage
鈥?4 External Interrupts
鈥?Programmable Watchdog Timer with Separate On-Chip Oscillator
Special Microcontroller Features
鈥?Low Power Idle, Noise Reduction, and Power Down Modes
鈥?Power On Reset and Programmable Brown Out Detection
鈥?Flag Array in Bit-programmable I/O Space (4 bytes)
鈥?In-System Programmable via SPI Port
鈥?Internal Calibrated RC Oscillator ( 8 MHz)
鈥?On-chip PLL for fast PWM ( 32 MHz, 64 MHz) and CPU (16 MHz)
Operating Voltage: 2.7V - 5.5V
Extended Operating Temperature:
鈥?-40擄C to +105擄
(full analog from -40 to 90擄C)
鈥?/div>
鈥?/div>
鈥?/div>
8-bit
Microcontroller
with 8K Bytes
In-System
Programmable
Flash
AT90PWM2
AT90PWM3
Preliminary
鈥?/div>
鈥?/div>
鈥?/div>
4317B鈥揂VR鈥?2/05
1
