AT88SC1616C Datasheet

  • AT88SC1616C

  • AT88SC1616C Summary [Updated 4/03. 14 Pages] 16-Kbit User Me...

  • 14頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Features
鈥?/div>
One of a Family of Devices with User Memories from 1 Kbit to 1 Mbit
鈥?/div>
16-Kbit (2-Kbyte) EEPROM User Memory
鈥?Sixteen 128-byte (1-Kbit) Zones
鈥?Self-timed Write Cycle (5 ms)
鈥?Single Byte or 16-byte Page Write Mode
鈥?Programmable Access Rights for Each Zone
鈥?/div>
2-Kbit Configuration Zone
鈥?37-byte OTP Area for User-defined Codes
鈥?160-byte Area for User-defined Keys and Passwords
鈥?/div>
High Security Features
鈥?64-bit Patented Dynamic Symetric Mutual Authentication Protocol (
under
exclusive patent license from
ELVA)
鈥?Encrypted Checksum
鈥?Stream Encryption
鈥?Four Key Sets for Authentication and Encryption
鈥?Eight Sets of Two 24-bit Passwords
鈥?Anti-tearing Function
鈥?Voltage and Frequency Monitor
鈥?/div>
Smart Card Features
鈥?ISO 7816 Class A (5V) or Class B (3V) Operation
鈥?ISO 7816-3 Asynchronous T = 0 Protocol
鈥?Multiple Zones, Key Sets and Passwords for Multi-application Use
鈥?Synchronous 2-wire Serial Interface for Faster Device Initialization
鈥?Programmable 8-byte Answer-To-Reset Register
鈥?ISO 7816-2 Compliant Modules
鈥?/div>
Embedded Application Features
鈥?Low Voltage Operation: 2.7V to 5.5V
鈥?Secure Nonvolatile Storage for Sensitive System or User Information
鈥?2-wire Serial Interface
鈥?1.5 MHz Compatibility for Fast Operation
鈥?Standard 8-lead Plastic Packages
鈥?Same Pinout as 2-wire Serial EEPROMs
鈥?/div>
High Reliability
鈥?Endurance: 100,000 Cycles
鈥?Data Retention: 10 years
鈥?ESD Protection: 4,000V min
CryptoMemory
廬
16 Kbit
AT88SC1616C
Summary
Table 1.
Pin Configuration
Pad
VCC
GND
SCL/CLK
SDA/IO
RST
Description
Supply Voltage
Ground
Serial Clock Input
Serial Data Input/Output
Reset Input
ISO Module Contact
C1
C5
C3
C7
C2
Standard Package Pin
8
4
6
5
NC
Card Module Contact
VCC = C1
RST = C2
SCL/CLK = C3
NC = C4
C5 = GND
C6 = NC
C7 = SDA/IO
C8 = NC
8-lead SOIC, PDIP or LAP
NC
NC
NC
GND
1
2
3
4
8
7
6
5
VCC
NC
SCL
SDA
Rev. 2030ES鈥揝MIC鈥?4/03
Note: This is a summary document. A complete document is
available under NDA. For more information, please contact your
1
local Atmel sales office.
