Features
鈥?/div>
Single-voltage Operation
鈥?/div>
鈥?/div>
鈥?/div>
鈥?5V Read
鈥?5V Reprogramming
Fast Read Access Time 鈥?55 ns
Internal Program Control and Timer
Sector Architecture
鈥?One 16K Bytes Boot Block with Programming Lockout
鈥?Two 8K Bytes Parameter Blocks
鈥?Four Main Memory Blocks (One 32K Bytes, Three 64K Bytes)
Fast Erase Cycle Time 鈥?4 Seconds
Byte-by-Byte Programming 鈥?20 碌s/Byte Typical
Hardware Data Protection
DATA Polling for End of Program Detection
Low Power Dissipation
鈥?25 mA Active Current
鈥?100 碌A(chǔ) CMOS Standby Current
Typical 10,000 Write Cycles
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
2-megabit
(256K x 8)
5-volt Only
Flash Memory
AT49F002A
AT49F002AN
AT49F002AT
AT49F002ANT
Description
The AT49F002A(N)(T) is a 5-volt only in-system reprogrammable Flash memory. Its
2 megabits of memory is organized as 262,144 words by 8 bits. Manufactured with
Atmel鈥檚 advanced nonvolatile CMOS technology, the device offers access times to
55 ns with power dissipation of just 137 mW over the industrial temperature range.
Pin Configurations
Pin Name
A0 - A17
CE
OE
WE
RESET
I/O0 - I/O7
Function
Addresses
Chip Enable
Output Enable
Write Enable
RESET
Data Inputs/Outputs
DIP Top View
* RESET
A16
A15
A12
A7
A6
A5
A4
A3
A2
A1
A0
I/O0
I/O1
I/O2
GND
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
VCC
WE
A17
A14
A13
A8
A9
A11
OE
A10
CE
I/O7
I/O6
I/O5
I/O4
I/O3
PLCC Top View
VSOP Top View (8 x 14 mm) or
TSOP Top View (8 x 20 mm)
Type 1
A14
A13
A8
A9
A11
OE
A10
CE
I/O7
A11
A9
A8
A13
A14
A17
WE
VCC
* RESET
A16
A15
A12
A7
A6
A5
A4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
OE
A10
CE
I/O7
I/O6
I/O5
I/O4
I/O3
GND
I/O2
I/O1
I/O0
A0
A1
A2
A3
I/O1
I/O2
GND
I/O3
I/O4
I/O5
I/O6
14
15
16
17
18
19
20
A7
A6
A5
A4
A3
A2
A1
A0
I/O0
5
6
7
8
9
10
11
12
13
4
3
2
1
32
31
30
A12
A15
A16
RESET *
VCC
WE
A17
29
28
27
26
25
24
23
22
21
3354D鈥揊LASH鈥?/03
Note:
*This pin is a NC on the AT49F002AN(T).
1
