AT24RF08C Datasheet

  • AT24RF08C

  • AT24RF08C [Updated 9/99. 25 Pages] Dual-interface IC with 8-...

  • 418.45KB

  • 21頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Features
鈥?/div>
Dual-port Nonvolatile Memory - RFID and Serial Interfaces
鈥?/div>
Two-wire Serial Interface:
鈥?Compatible with a Standard AT24C08 Serial EEPROM
鈥?Programmable Access Protection to Limit Reads or Writes from Either Port
鈥?Lock/Unlock Function, Coil Connection Detection
鈥?/div>
RFID Interface:
鈥?125 kHz Carrier Frequency for Long Range Access
鈥?2-Wire Connection to External Coil Antenna and Tuning Capacitor
鈥?Multi-tag Management to Handle Several Tags in the Field at Once
鈥?12 RFID Commands for Tag Control and Memory Read/Write
鈥?ID Write and Lock from RFID Port
鈥?Ultra Low Power Single Bit Write - 25 碌A(chǔ)
鈥?/div>
Highly-reliable EEPROM Memory
鈥?8K bits (1K bytes), Organized as 8 Blocks of 128 Bytes Each
鈥?16-byte Page Write, 10 ms Write Time
鈥?10 Years Retention, 100K Write Cycle Endurance
鈥?/div>
-40擄C to +85擄C Operation, 2.4V to 5.5V Supply, 8-Lead JEDEC SOIC Package
Asset
Identification
EEPROM
AT24RF08C
Description
The AT24RF08C functions as a dual access EEPROM, with both a wired serial port
and a wireless RFID port used to access the memory. Access permissions are set
from the serial interface side to isolate blocks of memory from improper access. The
RFID interface can be powered solely from the attached coil permitting remote reads
and writes of the device when VCC is not applied.
Block Diagram
Pin Configurations
Pin Name
L1
L2
PROT
GND
SDA
SCL
WP
VCC
Function
Coil Connection
Coil Connection
Protection Input
Ground
Serial Data,Open Drain I/O
Serial Clock Input
Write Protect Input
Supply: 2.4V - 5.5V
8-Pin SOIC
L1
L2
PROT
GND
1
2
3
4
8
7
6
5
VCC
WP
SCL
SDA
Rev. 1072E鈥?9/99
1
