AT1452

Preliminary Product Information

Photoflash Capacitor Charger for DSC

Features

鈥?2.5 to 5.5V supply voltage operating range.

鈥?Low current consumption: 1mA in operation,

鈥?50 kHz or 100kHz operation frequency .

鈥?Built-in maximum duty control.

鈥?push-pull output.

鈥?Built-in soft start circuit.

鈥?Built-in auto-discharge function.

General Description

The AT1452 is a charger control IC for Photoflash

capacitor with soft start function, adjustable

maximum duty cycle, auto refresh and auto-

discharge circuit. Adjustable soft start is

programmed with an external capacitor on SS pin.

It is ideal for DSC flash unit.

Applications

鈥igital Still Cameras flash unit

Block Diagram

Aimtron reserves the right without notice to change this circuitry and specifications.

2F, No.10, Prosperity RD. II, Science-Based Industrial Park, Hsinchu 300,Taiwan, R.O.C.

Tel: 886-3-563-0878

WWW:

http://www.aimtron.com.tw

Fax: 886-3-563-0879

Email:

service@aimtron.com.tw

1
