High Dynamic Range: 42dB Typical
Flat Attenuation vs. Frequency
High P1dB Compression
Operates on a Single +5V Supply:
SOW-16, Wide Body Package
50 Ohm Nominal Impedance
SOW-16
Description
M/A-COM's AT10-0019 is a Voltage Controlled PIN diode based
蟺
attenuator packaged in a low cost, 16 lead wide body plastic
SMT package. The PIN diode design makes this part well suited
for applications where low distortion or high linear operating
power levels are required. These attenuators are ideal for gain
control in multi-channel digital communications systems.
Ordering Information
Part Number
AT10-0019
AT10-0019TR
AT10-0019-TB
Package
Bulk Packaging
Tape and Reel
1
Unit Mounted on Test Board
1. Check with the factory for available quantities and reel size.
Package outline conforms to JEDEC standard MS-013AA.
Electrical Specifications
2
T
A
= +25擄C
Parameter
Insertion Loss
Dynamic Range
Attenuation
Flatness
VSWR
Trise, Tfall
Ton, Toff
Transients
1 dB
Compression
Test Conditions
Vcont.: +10 V
Vcont.: 0 V
Attenuation: 0 to 20 dB
Attenuation: 20 to 30 dB
Vcont.: 0 - 10V
10%/90%, 90%/10%
50% Cntl to 90%/10% RF
In-band
Vcont.: 0 - 10V
Frequency
50 - 1000 MHz
50 - 1000 MHz
50 - 1000 MHz
50 - 1000 MHz
50 - 1000 MHz
鈥?/div>
Units
dB
dB
dB
dB
Ratio
碌S
碌S
mV
dBm
dBm
dBm
Min
鈥?/div>
33
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
10
17
21
Typical
2.4
42
1.0
1.5
1.7:1
10
15
150
13
20
24
Max
2.8
鈥?/div>
1.5
2.0
2.1:1
20
25
250
鈥?/div>
鈥?/div>
鈥?/div>
100 MHz
500 MHz
1000 MHz
2. Unit requires external .01 碌F DC Blocks on RF lines.
Specifications subject to change without notice.
V 4.00
North America:
Tel. (800) 366-2266, Fax (800) 618-8883
Asia/Pacific:
Tel.+81-44-844-8296, Fax +81-44-844-8298
Europe:
Tel. +44 (1344) 869 595, Fax+44 (1344) 300 020
Visit www.macom.com for additional data sheets and product information.
