Instruction, True Bit Manipulation, Memory-mapped I/O
Operating Voltage: 3.0V 鹵 10% or 5.0V 鹵 10%
Meets GSM 11.11 & 11.12 Specifications and EMV 96 v3.1.1 Specification
5.0 MHz Maximum Internal Bus Frequency at 3.0V and 5.0V
ESD Protection to 鹵 4000V
Bond Pad Layout Conforming to ISO Standard ISO 7816/2
External Maskable Interrupt on ISO Standard I/O Port (PA0)
Power-saving WAIT and Very Low Power STOP Modes
Power-up Detection
Available as Sawn or Unsawn Wafers, or in Industry-standard Packages and Modules
EEPROM
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
8192 Bytes of EEPROM, including 16 Control Bytes and 48 OTP Bytes
1 to 64-byte Write/Program/Erase
1 ms Program Time, 1 ms Erase Time
10 Years Data Retention
Typically more than 1,000,000 Write/Erase Cycles
On-chip Charge Pump for EEPROM Programming, Driven by an Internal Oscillator
8-bit Secure
Microcontroller
with 8K
EEPROM and
Advanced
Security
Features
AT05SC2408R
Preliminary
RAM and ROM
鈥?/div>
24576 Bytes of ROM, including 16 Bytes Reserved for Vectors
鈥?/div>
512 Bytes of RAM with Security Wipe on Selected Areas
Peripherals
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Single Bidirectional I/O Line (1-bit ISO 7816/3 Standard I/O Port) with Sample Bit
Time Base Circuitry (with Preset and Maskable Interrupt Capabilities)
Watchdog Capability
CRC Module (allowing generation of Checksums (ISO/IEC 3309))
Random Number Generator
Security
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Dedicated Hardware to Resist Power Analysis Attacks
Low and High Voltage Monitors
Low and High Temperature Monitors
Low Frequency Monitor
High Frequency Filter/Monitor
Illegal Access Reset
Illegal Opcode Reset
Memory Partitioning with Address Lockout Reset
Scrambling Logic
Tamper Monitor
Physical Removal of Test Mode when Testing is Complete
Development Tools
鈥?/div>
Hardware Emulation Module (for the Motorola MMDS05
廬
Development System)
鈥?Emulation Module (AT05SCEM3R)
鈥?/div>
Software Simulator based on HIWARE鈥檚 HI-WAVE
廬
Product
鈥?Simulator Software (AT05SCRSIM)
鈥?Simulator I/O Peripheral Board (AT05SCSPBR)
Rev. 1545AS鈥?1/00
Note: This is a summary document. A complete document is
available under NDA. For more information, please contact your
local Atmel sales office.
1
