AS2715U-3.3 Datasheet

  • AS2715U-3.3

  • Analog IC

  • 9頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

AS2715
1.5A High Current Low Dropout Voltage Regulator
Adjustable & Fixed Output,
Fast Response
(ADVANCED INFORMATION)
FEATURES
鈥?/div>
Adjustable Output Down To 1.2V
鈥?/div>
1% output accuracy @ 2.5V, 3.3V& 5.0V
鈥?/div>
Output Current of 1.5A
鈥?/div>
Low Dropout Voltage of 350mV @ 1.5A
鈥?/div>
Extremely Tight Load And Line Regulation
鈥?/div>
Extremely Fast Transient Response
鈥?/div>
Reverse-battery and 鈥淟oad Dump鈥?Protection
鈥?/div>
Standard 3-Terminal Low Cost TO-220, TO-263
APPLICATIONS
鈥?/div>
Powering VGA & Sound Card
鈥?/div>
LCD Monitors
鈥?/div>
USB Power Supply
鈥?/div>
Power PC餂?Supplies
鈥?/div>
SMPS Post-Regulator
鈥?/div>
High Efficiency 鈥淕reen鈥?Computer Systems
鈥?/div>
High Efficiency Linear Power Supplies
鈥?/div>
Portable Instrumentation
鈥?/div>
Constant Current Regulators
鈥?/div>
Adjustable Power Supplies
鈥?/div>
Battery Charger
PRODUCT DESCRIPTION
The AS2715 is a 1.5A high accuracy, low dropout voltage regulator with only 350mV(Typ.)@ 1.5A). The AS2715 is designed for
low voltage application that requires lower dropout voltage and faster transient response. This device is an excellent choice for use in
powering low voltage microprocessor that require a lower dropout, faster transient response to regulate from +2.5V to 3.8V supplies
and as a post regulator for switching supplies applications.
The AS2715 offers full protection against over-current faults, reversed input polarity, reversed load insertion, and positive and
negative transient voltage. On-Chip trimming adjusts the reference voltage to 1%. Features such as Enable pin, Error Flag pin are
also included in the 5 pin packages.
The AS2715 is offered in a 3 & 5-pin TO-220 & TO-263 package compatible with other 3 terminal regulators. For a 3A low dropout
regulator refer to the AS2730 data sheet.
ORDERING INFORMATION
TO-220
TO-263
3-PIN
3-PIN
AS2715U-X
AS2715T-X
X = Output Voltage (2.5V, 3.3V, 5.0V or Blank for Adjustable.)
Consult with factory for other fixed output voltages.
PIN CONNECTIONS
TO-263-3 Package
TO-220-3 Package
AS2715
1
2
3
AS2715
V
IN
GND V
OUT
Front View
V
IN
GND V
OUT
Front View
Rev. 10/11/00
