GaAs SPST High Isolation Switch
DC鈥?.5 GHz
AS130-73
Features
s
Low Insertion Loss (0.75 dB @ 0.9 GHz)
s
Low DC Power Consumption
s
Ultra Miniature SOT-6 Lead Package
s
Reflective Open, J
1
Port
s
Non-Reflective, J
2
Port
SOT-6
0.074
(1.90 mm REF.)
PIN 6
PIN 1
INDICATOR
PIN 1
0.020 (0.51 mm)
0.014 (0.350 mm)
0.057 (1.45 mm)
0.035 (0.90 mm)
0.126 (3.20 mm)
0.087 (2.20 mm)
0.071 (1.80 mm)
0.052 (1.30 mm)
0.037 (0.95 mm) REF.
0.012
(0.30 mm)
TYP.
0.014
(0.26 mm)
0.004
(0.10 mm)
5.0藲 鹵 1藲
Description
The AS130-73 is a high isolation GaAs MMIC FET IC
SPST Switch in the SOT-6 low cost plastic package for
commercial applications. Switch is matched on J
2
port and
reflective on J
1
port when in isolation state.
0.006
(0.15 mm)
0.000
(0.00 mm)
5.0藲 鹵 1藲
0.122 (3.10 mm)
0.106 (2.70 mm)
0.022 (0.61 mm)
0.004 (0.10 mm)
Electrical Specifications at 25擄C (0, -5 V)
Parameter
1
Insertion Loss
3
Frequency
2
DC鈥?.5
DC鈥?.0
DC鈥?.0
DC鈥?.5
DC鈥?.5
DC鈥?.0
DC鈥?.0
DC鈥?.5
GHz
GHz
GHz
GHz
GHz
GHz
GHz
GHz
46
35
23
18
Min.
Typ.
0.75
0.8
0.9
1.0
53
41
28
24
1.15:1
1.3:1
1.2:1
1.5:1
Max.
1.0
1.0
1.1
1.2
Unit
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
Isolation
VSWR
4
DC鈥?.0 GHz
DC鈥?.5 GHz
Operating Characteristics at 25擄C (0, -5 V)
Parameter
Switching Characteristics
5
Condition
Rise, Fall (10/90% or 90/10% RF)
On, Off (50% CTL to 90/10% RF)
Video Feedthru
0.5鈥?.0 GHz
For Two-tone Input Power +13 dBm
0.5鈥?.0 GHz
V
Low
= 0 to -0.2 V @ 20 碌A(chǔ) Max.
V
High
= -5 V @ 50 碌A(chǔ) to -8 V @ 200 碌A(chǔ) Max.
Frequency
Min.
Typ.
5
10
15
+25
+44
Max.
Unit
ns
ns
mV
dBm
dBm
Input Power for 1 dB Compression
Intermodulation Intercept Point (IP3)
Control Voltages
1. All measurements made in a 50
鈩?/div>
system, unless otherwise specified.
2. DC = 300 kHz.
3. Insertion loss changes by 0.003 dB/擄C.
4. Insertion loss state and isolation state @ J
2
port.
5. Video feedthru measured with 1 ns risetime pulse and 500 MHz bandwidth.
Alpha Industries, Inc.
[781] 935-5150
鈥?/div>
Fax
[617] 824-4579
鈥?/div>
Email
sales@alphaind.com
鈥?/div>
www.alphaind.com
Specifications subject to change without notice. 3/99A
