GaAs IC Transfer Switch DC鈥? GHz
AS126-62
Features
s
High Linearity (IP3 45 dBm @ 0.9 GHz)
s
Low Insertion Loss (0.6 dB @ 0.9 GHz)
s
Simultaneous T/R Switching
0.220 (5.60 mm)
0.197 (5.00 mm)
0.323 (8.20 mm)
0.291 (7.40 mm)
SSOP-8
Description
The AS126-62 is a 4 port switch designed to combine T/R
and antenna changeover switching capability within one
device. This switch has two DC voltage controls and is
ideal for -5 V applications having low power consumption
requirements. The AS126-62 is suitable for cellular
wireless communication applications.
PIN 1
INDICATOR
0.129 (3.30 mm)
0.106 (2.70 mm)
0.079
(2.0 mm)
REF.
0.0256 (0.65 mm) TYP.
R 0.004
(0.10 mm)
MIN.
0藲鈥?藲
R 0.004
(0.10 mm) MIN.
A
C
A
SEATING
0.008 (0.20 mm)
0.010 (0.25 mm) BSC
PLANE
0.002 (0.05 mm)
GAGE PLANE
0.038 (0.97 mm)
0.012 (0.30 mm) REF.
0.022 (0.56 mm)
Electrical Specifications at 25擄C (0, -5 V)
Parameter
1
Insertion Loss
3
Frequency
2
DC鈥?.5 GHz
DC鈥?.0 GHz
DC鈥?.0 GHz
DC鈥?.5 GHz
DC鈥?.0 GHz
DC鈥?.0 GHz
DC鈥?.0 GHz
DC鈥?.0 GHz
19
13
8
Min.
Typ.
0.55
0.6
1.3
26
15
11
1.1:1
1.3:1
1.5:1
1.8:1
Max.
0.6
0.7
1.6
Unit
dB
dB
dB
dB
dB
dB
Isolation
4
VSWR
5
Operating Characteristics at 25擄C (0, -5 V)
Parameter
Switching Characteristics
6
Condition
Rise, Fall (10/90% or 90/10% RF)
On, Off (50% CTL to 90/10% RF)
Video Feedthru
For Two-tone Input Power +0 dBm
0.5鈥?.0 GHz
0.5鈥?.0 GHz
V
Low
= 0 to -0.2 V @ 10 碌A(chǔ) Max.
V
High
= -5 V @ 25 碌A(chǔ) to -10 V @ 100 碌A(chǔ) Max.
Frequency
Min.
Typ.
20
40
50
+45
+33
Max.
Unit
ns
ns
mV
dBm
dBm
Intermodulation Intercept Point (IP3)
Input Power For 1 dB Compression (T
X
)
Control Voltages
1. All measurements made in a 50 ohm system, unless otherwise specified.
2. DC = 300 kHz.
3. Insertion loss changes by 0.003 dB/擄C.
4. Any state.
5. Insertion loss state.
6. Video feedthru measured with 1 ns risetime pulse and 500 MHz bandwidth.
Alpha Industries, Inc.
[781] 935-5150
鈥?/div>
Fax
[617] 824-4579
鈥?/div>
Email
sales@alphaind.com
鈥?/div>
www.alphaind.com
Specifications subject to change without notice. 3/98A
