(AQY210EH). Stable
operation because there are no metallic
contact parts.
5. Low-level off state leakage current
The SSR has an off state leakage current
of several milliamperes, whereas the Pho-
toMOS relay has only 100 pA even with
the rated load voltage of 350 V
(AQY210EH).
mm
inch
1. Reinforced insulation 5,000 V type
More than 0.4 mm internal insulation dis-
tance between inputs and outputs. Con-
forms to EN41003, EN60950 (reinforced
insulation).
2. Compact 4-pin DIP size
The device comes in a compact
(W)6.4
脳
(L)4.78
脳
(H)3.2mm
(W).252
脳
(L).188
脳
(H).126inch,
4-pin DIP size.
3. Controls low-level analog signals
PhotoMOS relays feature extremely low
closed-circuit offset voltage to enable
control of low-level analog signals without
distortion.
4. High sensitivity, low ON resistance
Can control a maximum 0.13 A load cur-
rent with a 5 mA input current. Low ON re-
TYPICAL APPLICATIONS
鈥?Modem
鈥?Telephone equipment
鈥?Security equipment
鈥?Sensors
TYPES
Part No.
Output rating*
Type
I/O isolation
voltage
Load
voltage
AC/DC
type
Reinforced
5,000 V
350 V
400 V
Load
current
130 mA
120 mA
Through hole
terminal
Tube packing style
AQY210EH
AQY214EH
AQY210EHA
AQY214EHA
Surface-mount terminal
Tape and reel packing style
Picked from the Picked from the
1/2-pin side
3/4-pin side
AQY210EHAX AQY210EHAZ
AQY214EHAX
AQY214EHAZ
Packing quantity
Tube
Tape and
reel
1 tube contains 100 pcs.
1,000 pcs.
1 batch contains 1,000 pcs.
*Indicate the peak AC and DC values.
Note: For space reasons, the initial letters of the product number "AQY", the SMD terminal shape indicator "A" and the package type indicator "X" and "Z" are omitted from
the seal.
RATING
1. Absolute maximum ratings (Ambient temperature: 25
擄
C
77
擄
F)
Item
LED forward current
Input
LED reverse voltage
Peak forward current
Power dissipation
Sym-
bol
I
F
V
R
I
FP
P
in
V
L
I
L
I
peak
P
out
P
T
V
iso
T
opr
T
stg
350 V
0.13 A
0.4 A
500mW
550mW
5,000 V AC
鈥?0
擄
C to +85
擄
C
鈥?0
擄
F to +185
擄
F
鈥?0
擄
C to +100
擄
C
鈥?0
擄
F to +212
擄
F
Non-condensing at low temperatures
AQY210EH (A)
50mA
3V
1A
75mW
400 V
0.12 A
0.3 A
f =100 Hz, Duty factor = 0.1%
AQY214EH (A)
Remarks
Load voltage (peak AC)
Continuous load current
Output
Peak load current
Power dissipation
Total power dissipation
I/O isolation voltage
Temperature
limits
Operating
Storage
100 ms (1 shot), V
L
= DC
520
1
2
3
