GU (General Use) Type
[2-Channel (Form B) Type]
PhotoMOS
RELAYS
5. Controls load currents up to 0.13 A
with an input current of 5 mA
6. High speed switching: operate time
typical of 300
碌
s
7. Eliminates the need for a power sup-
ply to drive the power MOSFET
8. Extremely low closed-circuit offset
voltages to enable control of small an-
alog signals without distortion
9. Surface-mount model available
FEATURES
9.78
.385
6.4
.252
3.9鹵0.2
.154鹵.008
6.4
.252
3.6鹵0.2
.142鹵.008
1. Approx. 1/2 the space compared
with the mounting of Two 1 Form B
photo MOS units
Two 1 Form B units
9.78
.385
2 Form B type
mm
inch
2. Applicable for 2 Form B use as well
as two independent 1 Form B use
3. Low thermal electromotive force
(Approx. 1
碌
V)
4. Eliminates the need for a counter
electromotive force protection diode in
the drive circuits on the input side
TYPICAL APPLICATIONS
鈥?High-speed inspection machines
鈥?Telephone equipment
鈥?Computer
TYPES
Output rating*
Type
Through hole
terminal
Load
voltage
Load
current
Tube packing style
Part No.
Surface-mount terminal
Tape and reel packing style
Picked from the
Picked from the
1/2/3-pin side
4/5/6-pin side
AQW414AX
AQW414AZ
Packing quantity
Tube
1 tube contains
40 pcs.
1 batch contains
400 pcs.
Tape and reel
AC/DC type
400 V
100 mA
AQW414
AQW414A
1,000 pcs
*Indicate the peak AC and DC values.
Note: For space reasons, the package type indicator "X" and "Z" are omitted from the seal.
RATINGS
1. Absolute maximum ratings (Ambient temperature: 25
擄
C
77
擄
F)
Item
LED forward current
LED reverse voltage
Peak forward current
Power dissipation
Load voltage
Output
Continuous load current
Symbol
I
F
V
R
I
FP
P
in
V
L
I
L
I
peak
P
out
P
T
V
iso
T
opr
T
stag
AQW414(A)
50 mA
3V
1A
75 mW
400 V
0.1 A (0.13 A)
0.3 A
800 mW
850 mW
1,500 V AC
鈥?0
擄
C to +85
擄
C
鈥?0
擄
F to +185
擄
F
鈥?0
擄
C to +100
擄
C
鈥?0
擄
F to +212
擄
F
Peak AC, DC
( ): in case of using only 1 channel
100 ms (1 shot), V
L
= DC
Remarks
Input
f = 100 Hz, Duty factor = 0.1%
Peak load current
Power dissipation
Total power dissipation
I/O isolation voltage
Temperature limits
Operating
Storage
Non-condensing at low temperatures
