TYPICAL APPLICATIONS
1. Home appliances (air conditioners,
microwave ovens, washing machines,
personal hygiene systems,
refrigerators, fan heaters, inductive
heating cooker, and water heaters,
etc.)
2. Industrial equipment market.
6
5
DIP8
DIP16
(mm
inch)
19.82
.780
4. Only ours handles both 100 and 200
V AC loads
This relay handles both voltages in a
single product. It is not necessary for
users that use both types to manage
separate part numbers.
TYPES
Part No.
Output rating*
Type
Repetitive
ON-state
peak OFF-
RMS current
state voltage
0.3 A
0.6 A
0.9 A
AC
type
600 V
1.2 A
0.3 A
0.6 A
0.9 A
1.2 A
Type
Through hole
terminal
Tube packing style
AQH0213
AQH1213
AQH2213
AQH3213
AQH0223
AQH1223
AQH2223
AQH3223
AQH0213A
AQH1213A
AQH2213A
AQH3213A
AQH0223A
AQH1223A
AQH2223A
AQH3223A
Surface-mount terminal
Tape and reel packing style
Picked from the Picked from the
1/2/3/4-pin side 5/6/8-pin side
AQH0213AX
AQH1213AX
AQH2213AX
AQH3213AX
AQH0223AX
AQH1223AX
AQH2223AX
AQH3223AX
AQH0213AZ
AQH1213AZ
AQH2213AZ
AQH3213AZ
AQH0223AZ
AQH1223AZ
AQH2223AZ
AQH3223AZ
Packing quantity
Tube
Tape and
reel
Zero-cross
1 tube contains
40 pcs.
1,000 pcs.
1 batch contains
400 pcs.
Non zero-cross
*Indicate the repetitive peak OFF-state voltage and ON-state RMS current: peak AC.
Note: For space reasons, the SMD terminal shape indicator 鈥淎鈥?and the package type indicator 鈥淴鈥?and 鈥淶鈥?are omitted from the seal.
RATING
1. Absolute maximum ratings
(Ambient temperature: 25擄C
77擄F)
Item
LED forward current
Input
LED reverse voltage
Peak forward current
Repetitive peak OFF-state votage
Output ON-state RMS current
Non-repetitive surge current
I/O isolation voltage
Temperature limits
Operating
Storage
Symbol
AQH0213 AQH0223 AQH1213 AQH1223 AQH2213 AQH2223 AQH3213 AQH3223
I
F
50 mA
V
R
6V
I
FP
V
DRM
IT
(RMS)
I
TSM
V
iso
T
opr
T
stg
0.3 A
3A
0.6 A
6A
5,000 V AC
鈥?0擄C to +85擄C
鈥?2擄F to +185擄F
鈥?0擄C to +125擄C
鈥?0擄F to +257擄F
Non-condensing at
low temperatures
1A
600 V
0.9 A
9A
1.2 A
12 A
60Hz, 1 cycle
Remarks
f = 100 Hz,
Duty Ratio = 0.1%
AQ-H SOLID STATE RELAY
