APTGT150DH170G Datasheet

  • APTGT150DH170G

  • Asymmetrical - Bridge Trench + Field Stop IGBT Power Module

  • 5頁

  • MICROSEMI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

APTGT150DH170G
Asymmetrical - Bridge
Trench + Field Stop IGBT
廬
Power Module
VBUS
Q1
G1
CR3
V
CES
= 1700V
I
C
= 150A @ Tc = 80擄C
Application
鈥?/div>
Welding converters
鈥?/div>
Switched Mode Power Supplies
鈥?/div>
Switched Reluctance Motor Drives
Features
鈥?/div>
Trench + Field Stop IGBT
廬
Technology
- Low voltage drop
- Low tail current
- Switching frequency up to 20 kHz
- Soft recovery parallel diodes
- Low diode VF
- Low leakage current
- Avalanche energy rated
- RBSOA and SCSOA rated
鈥?/div>
Kelvin emitter for easy drive
鈥?/div>
Very low stray inductance
- Symmetrical design
- M5 power connectors
鈥?/div>
High level of integration
Benefits
鈥?/div>
Stable temperature behavior
鈥?/div>
Very rugged
鈥?/div>
Direct mounting to heatsink (isolated package)
鈥?/div>
Low junction to case thermal resistance
鈥?/div>
Easy paralleling due to positive TC of VCEsat
鈥?/div>
Low profile
鈥?/div>
RoHS Compliant
E1
OUT1 OUT2
Q4
G4
CR2
E4
0/VBUS
OUT1
G1
E1
VBUS
0/VBUS
E4
G4
OUT2
Absolute maximum ratings
Symbol
V
CES
I
C
I
CM
V
GE
P
D
RBSOA
Parameter
Collector - Emitter Breakdown Voltage
Continuous Collector Current
Pulsed Collector Current
Gate 鈥?Emitter Voltage
Maximum Power Dissipation
T
C
= 25擄C
T
C
= 80擄C
T
C
= 25擄C
T
C
= 25擄C
T
j
= 125擄C
Reverse Bias Safe Operating Area
300A @ 1600V
These Devices are sensitive to Electrostatic Discharge. Proper Handing Procedures Should Be Followed. See application note
APT0502 on www.microsemi.com
www.microsemi.com
1-5
APTGT150DH170G 鈥?Rev 1
July, 2006
Max ratings
1700
250
150
300
鹵20
890
Unit
V
A
V
W

APTGT150DH170G 產品屬性

  • 1

  • 半導體模塊

  • IGBT

  • -

  • 溝道和場截止

  • 非對稱橋

  • 1700V

  • 2.4V @ 15V，150A

  • 250A

  • 350µA

  • 13.5nF @ 25V

  • 890W

  • 標準型

  • 無

  • 底座安裝

  • SP6

  • SP6
