APCI-RELAY8/IN8 Datasheet

  • APCI-RELAY8/IN8

  • PCI-BUS I/O CARD

  • 8頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

J594 APCI-RELAY8/IN8
2192-09101-000-000
APCI-RELAY8/IN8
Introduction
The APCI-RELAY8/IN8 is a 32-bit PCI local BUS board which provides 8 changeover relays and 8 opto
isolated digital input signals. Each relay has a power rating of 60W (resistive load). This allows
switching of voltages up to 48V DC (to meet low voltage directive) and currents of up to 1.0A.
Features
聲
聲
聲
聲
聲
聲
聲
聲
聲
聲
聲
聲
聲
聲
聲
聲
8 Changeover relays with power switching rating of 60W (resistive load)
Switching voltage up to 48V DC (to meet low voltage directive) and currents up to 1.0A
8 Opto Isolated inputs with current limiting resistors
Opto input switching voltage 10V to 30V
Relay status readback register
N.O. and N.C. contacts provided at connector
Relay drivers disabled at power-up and reset
Link selectable debounce option on inputs
Board access LED
PCI 2.1 Compatible Bus interface
Plug and Play software compatible
Operating Temperature range 0 to +70C
Relay operating life 500,000 operations (DC Full load)
CE Compliant design
Power Consumption 60mA + 30mA per relay operating @ +5V
MTBF 323,293 hours (using generic figures from MIL-HDBK-217F at benign ground)
Getting Started
聲
聲
聲
聲
Power down your PC system.
Install the board in a spare PCI Slot (See Installation for CE compliance).
Power up system with MSDOS.
Run APCI.EXE (supplied on the utility disk), this will search for the board and check I/O access. If
this fails, check board is correctly l0cated.
Warning
This board contains CMOS devices which may be damaged by static electricity. Please ensure anti-
static precautions are taken at all times when handling this board. If for any reason this board is
returned to Arcom Control Systems, please ensure it is adequately packed to prevent damage during
shipment.
Page 1
