Supports PMC Sierra single and quad chipsets for T1/E1 applications including PM4351 and PM4354
Minimum board space requirement, ideal for multiple interface line cards
Telcordia Technologies GR1089 compliant
Approved to BSEN60950, basic insulation @ 250Vrms working voltage
Designed to minimize board space requirements for line interfce circuitry on the T1/E1 multichannel line cards
Analog receive inteface is configurable to operate both E1 and T1 short haul and long haul applications
SCHEMATIC
APC822xx
12
1
13-TVREF
3 TX
10
2
9
4
5 RX
7
11-GND
8-VCC
6
漏2003 Bel Fuse Inc. Specifications subject to change without notice. 08.20.03
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com
Page 1
