Designed to interface with Alcatel鈥檚 Quad MTK20450 ADSL transceiver chipset, the dual SMD
mechanical form is intended to optimize board space in Central Office (CO) high density line
card applications
Optimized rate/reach performance
Contains every component required between the analog front end chip and the connector, including line interface
transformer and receive filters (excluding the line driver and associated resistor network)
Suitable for pick and place manufacturing
Approval is pending for BS EN60950 / IEC60950 / TS 001 / AS/NZS3260 / CAN/CSA C22.2 Np. 950-95 / UL1950 / UL
Component Recognition and CB Certificate
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
SCHEMATIC
Channel 1
RX FILTER
RXP (14)
RX GR OU ND (12)
RXN (13)
TNV
SIDE
TIP (2)
SELV
SIDE
RING (1)
LINE
INTERFACE
TRANSFORMER
2 TO 4 WIRE
CON VERSION
TXP (11)
TXN (10)
Channel 2
RX FILTER
RXP (9)
RX GR OU ND (7)
RXN (8)
TNV
SIDE
TIP (4)
SELV
SIDE
RING (3)
LINE
INTERFACE
TRANSFORMER
2 TO 4 WIRE
CON VERSION
TXP (6)
TXN (5)
NOTE: DETAILED SCHEMATIC AVAILABLE TO ALCATEL/APC NDA CUSTOMERS
漏2003 Bel Fuse Inc. Specifications subject to change without notice. 05.20.03
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com
