Designed for Broadcom BCM6315 and BCM6020 VDSL chipsets
Plan998 based symmetric CO design
Includes band pass line filter, 2 wire line interface hybrid, TX and RX filters and AGC control
1500V line isolation transformer
Minimum surface mount footprint for increased line card density
BLOCK DIAGRAM
ELECTRICAL SPECIFICATIONS@25擄C
OPERATING TEMPERATURE -40擄C TO +85擄C
Description
VDSL LPF (TX)
VDSL HPF (RX)
Passband Freq
400kHz to 3.5MHz
3.9MHz >
Stopband Freq
>3.9MHz
DC to 3.5MHz
Attenuation
min
35dB
35dB
漏2003 Bel Fuse Inc. Specifications subject to change without notice. 08.19.03
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com
page 1
