SMD ISDN S Interface Hybrid
APC5568ds-5v
ELECTRICAL SPECIFICATIONS @ 25擄C
Choke
Primary
Inductance
mH min
22
Leakage
Inductance
uH max
5.0
Primary
DCR
OHMS
+/- 30%
2.2
Secondary
DCR
OHMS
+/- 30%
2.8
Inductance
per line
mH nom
0.04
DCR
per line
OHMS
0.5
Turns Ratio
+/-5%
1CT:2
NOTES:
ISOLATION PRI:SEC 1500VRMS
APPROVALS PENDING FOR IEC6950:A4:1996 AND EN60950:A4:1997
DESIGNED FOR USE WITH MOTOROLA MC145575 AND COLOGNE HFC-SXX
EXTERNAL RESISTORS R1 AND R1鈥?REQUIRED FOR AMPLITUDE OPTIMIZATION. RECOMMENDED VALUE 560 OHMS
MECHANICAL
3.76
[0.15]
0.1[0.004]
5.08
[0.2]
20.32
[0.8]
5.08
[0.2]
3.76
[0.15]
18
13
38.00
[1.49]
20.00
[0.78]
16.60
[0.66]
9.8 MAX
[0.38]
1.00
[0.04]
Sideelevation
Endelevation
2.54
[0.1]
0.96
[0.04]
30.48
[1.2]
12
1
Componentbodyoutline
PlanviewofsuggestedPCBpadlayout
NOTES:
NOT TO SCALE
TOLERANCE+/- 0.2MM
ALL DIMENSIONS IN MM [INCHES]
漏2003 Bel Fuse Inc. Specifications subject to change without notice. 05.20.03
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com
Page 1
