PCMCIA 鈥淪鈥?Interface Module
APC48301
ELECTRICAL SPECIFICATIONS @ 25擄C
Turns
Ratio
LINE:IC
1CT:2CT
NOTES:
Primary
Inductance
(9-12,13-16)
mH min
20.0
Primary
DCR
OHMS
+/-15%
(9-12,13-16)
1.0
Secondary
DCR
OHMS
+/-15%
(1-4, 5-8)
1.5
Choke
Leakage
Inductance
uH max
10.0
Capacitance
w/w
pF max
60.0
Inductance
per line
mH nom
0.04
DCR
per line
OHMS
0.2(NOM)
PRIMARY PINS 9-12, 13-16
ISOLATION PRI:SEC 1500VRMS
SCHEMATIC
1
16
3
15
4
5
13
12
6
10
8
MECHANICAL
27.20
17.78
0.50
16
15
14
13
9
3.11
2.54
12
11
10
9
2.5
MAXHEIGHT
18.11
15.00
1
2
3
4
5
6
7
8
漏2003 Bel Fuse Inc. Specifications subject to change without notice. 05.20.03
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com
Page 1
