AMS2950 Datasheet

  • AMS2950

  • Advanced Monolithic Systems [150mA LOW DROPOUT VOLTAGE REGU...

  • ADMOS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Advanced
Monolithic
Systems
FEATURES
鈥?/div>
5.0V, 3.3V, 3.0V and 2.5V Versions
鈥?/div>
High Accuracy Output Voltage
鈥?/div>
Extremely Low Quiescent Current
鈥?/div>
Low Dropout Voltage
鈥?/div>
Extremely Tight Load and Line Regulation
鈥?/div>
Very Low Temperature Coefficient
鈥?/div>
Current and Thermal Limiting
鈥?/div>
Needs Minimum Capacitance (1碌F) for Stability
碌
鈥?/div>
Unregulated DC Positive Transients 60V
鈥?/div>
1.24V to 29V Programmable Output
鈥?/div>
Error Flag Warning of Voltage Output Dropout
鈥?/div>
Logic Controlled Electronic Shutdown
AMS2950/AMS2951
150mA LOW DROPOUT VOLTAGE REGULATOR
APPLICATIONS
鈥?/div>
Battery Powered Systems
鈥?/div>
Portable Consumer Equipment
鈥?/div>
Cordless Telephones
鈥?/div>
Portable (Notebook) Computers
鈥?/div>
Portable Instrumentation
鈥?/div>
Radio Control Systems
鈥?/div>
Automotive Electronics
鈥?/div>
Avionics
鈥?/div>
Low-Power Voltage Reference
ADDITIONAL FEATURES (AMS2951 ONLY)
GENERAL DESCRIPTION
The AMS2950 and AMS2951 are micropower voltage regulators ideally suited for use in battery-powered systems. These
devices feature very low quiescent current (typ.75碌A), and very low dropout voltage (typ.45mV at light loads and 380mV at
150mA) thus prolonging battery life. The quiescent current increases only slightly in dropout. The AMS2950/AMS2951 has
positive transient protection up to 60V and can survive unregulated input transient up to 20V below ground.
The AMS2950 and AMS2951 were designed to include a tight initial tolerance (typ. 0.5%), excellent load and line regulation
(typ. 0.05%), and a very low output voltage temperature coefficient, making these devices useful as a low-power voltage
reference
.
The AMS2950 is offered in the 3-pin TO-92 package. AMS2951 is available in 8-pin plastic SOIC and DIP packages and
offers three major additional system features. An error flag output warns of a low output voltage, often due to failing batteries
on input. The AMS2951 also features the logic-compatible shutdown input which enables the regulator to be switched on and
off. The AMS2951 device may be pin-strapped for a 5.0V, 3.3V, 3.0V or 2.5 output, or programmed from 1.24V to 29V with
an external pair of resistors.
ORDERING INFORMATION
PACKAGE TYPE
TO-92
8 LEAD PDIP 8 LEAD SOIC
AMS2950ACN-X AMS2951ACP- AMS2951ACS-X
AMS2950CN-X AMS2951CP-X AMS2951CS-X
X = 3.3V, 3.0V, 2.5V
OPERATING
TEMP. RANGE
IND.
IND
PIN CONNECTION
8L SOIC/ 8L PDIP
OUTPUT 1
SENSE 2
SHUTDOWN 3
GROUND 4
8 INPUT
7 FEEDBACK
6 V
TAP
5 ERROR
Top View
TO-92
OUTPUT
INPUT
GND
Bottom View
Advanced Monolithic Systems, Inc.
6680B Sierra Lane, Dublin, CA 94568 Phone (925) 556-9090 Fax (925) 556-9140
