ADXL330 Datasheet

  • ADXL330

  • Small, Low Power, 3-Axis ±2 g i MEMS? Accelerometer

  • 9頁

  • AD

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Small, Low Power, 3-Axis 鹵3
g
i
MEMS
廬
Accelerometer
ADXL330
FEATURES
3-axis sensing
Small, low-profile package
4 mm 脳 4 mm 脳 1.45 mm LFCSP
Low power
200 渭A at V
S
= 2.0 V (typical)
Single-supply operation
2.0 V to 3.6 V
10,000
g
shock survival
Excellent temperature stability
BW adjustment with a single capacitor per axis
RoHS/WEEE lead-free compliant
GENERAL DESCRIPTION
The ADXL330 is a small, thin, low power, complete three axis
accelerometer with signal conditioned voltage outputs, all
on a single monolithic IC. The product measures acceleration
with a minimum full-scale range of 鹵3
g.
It can measure the
static acceleration of gravity in tilt-sensing applications, as well
as dynamic acceleration resulting from motion, shock, or
vibration.
The user selects the bandwidth of the accelerometer using the
C
X
, C
Y
, and C
Z
capacitors at the X
OUT
, Y
OUT
, and Z
OUT
pins.
Bandwidths can be selected to suit the application, with a
range of 0.5 Hz to 1,600 Hz for X and Y axes, and a range of
0.5 Hz to 550 Hz for the Z axis.
The ADXL330 is available in a small, low-profile, 4 mm 脳 4 mm
脳 1.45 mm, 16-lead, plastic lead frame chip scale package
(LFCSP_LQ).
APPLICATIONS
Cost-sensitive, low power, motion- and tilt-sensing
applications
Mobile devices
Gaming systems
Disk drive protection
Image stabilization
Sports and health devices
FUNCTIONAL BLOCK DIAGRAM
+3V
V
S
ADXL330
OUTPUT AMP
3-AXIS
SENSOR
C
DC
AC AMP
DEMOD
OUTPUT AMP
R
FILT
X
OUT
C
X
R
FILT
Y
OUT
C
Y
R
FILT
OUTPUT AMP
Z
OUT
C
Z
05677-001
COM
ST
Figure 1.
Rev. 0
Information furnished by Analog Devices is believed to be accurate and reliable. However, no
responsibility is assumed by Analog Devices for its use, nor for any infringements of patents or other
rights of third parties that may result from its use. Specifications subject to change without notice. No
license is granted by implication or otherwise under any patent or patent rights of Analog Devices.
Trademarks and registered trademarks are the property of their respective owners.
One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: 781.329.4700
www.analog.com
Fax: 781.461.3113
漏2006 Analog Devices, Inc. All rights reserved.
