FEATURES
250 MHz Operation
Driver/Comparator Included
52-Lead LQFP Package with Built-in Heat Sink
High Performance Driver/Comparator
on a Single Chip
AD53033
FUNCTIONAL BLOCK DIAGRAM
V
CC
VH
47
VTERM
45
DATA
37
DATAB
38
IOD
43
IODB
42
RLD
49
RLDB
50
V
L 31
HCOMP
LEH
LEHB
QH
QHB
50
DRIVER
V
OUT
VLDCPL
VHDCPL
V
CC
V
CC
51
52
V
EE
32
V
EE
39
V
EE
40
V
EE
41
APPLICATIONS
Automatic Test Equipment
Semiconductor Test Systems
Board Test Systems
Instrumentation and Characterization Equipment
AD53033
PRODUCT DESCRIPTION
COMPARATOR
QL
QLB
LEL
LELB
LCOMP
The AD53033 is a single chip that performs the pin electronics
functions of driver and comparator (D-C) in ATE VLSI and
memory testers.
The driver is a proprietary design that features three active
states: Data High Mode, Data Low Mode and Term Mode as
well as an Inhibit State. This facilitates the implementation of
high speed active termination. The output voltage range is 鈥? V
to +8 V to accommodate a wide variety of test devices. The
output leakage is typically less than 250 nA over the entire sig-
nal range.
The dual comparator, with an input range equal to the driver
output range, features built-in latches and ECL-compatible
outputs. The outputs are capable of driving 50
鈩?/div>
signal lines
terminated to 鈥? V. Signal tracking capability is upwards of
5 V/ns.
Also included on the chip is an onboard temperature sensor
whose purpose is to give an indication of the surface tempera-
ture of the D-C. This information can be used to measure
胃
JC
and
胃
JA
or flag an alarm if proper cooling is lost. Output from the
NC
THERM
1.0 A/K
9, 33, 44, 46, 48
2, 5, 8
PWRGND
NC = NO CONNECT
ECLGND
HQGND2
sensor is a current sink that is proportional to absolute tempera-
ture. The gain is trimmed to a nominal value of 1.0
碌A(chǔ)/K.
As
an example, the output current can be sensed by using a 10 k鈩?/div>
resistor connected from +10 V to the THERM (IOUT) pin. A
voltage drop across the resistor will be developed that equals:
10K
脳
1
碌A(chǔ)/K
= 10 mV/K = 2.98 V at room temperature.
