AD42211
2 Form A
Solid State Relay
DESCRIPTION
The AD42211 is a bi-directional, double-pole, single-throw, normally open multipurpose solid-state relay. It is designed to replace
electromechanical relays in general purpose switching applications. The relay consists of two integrated circuits, each driving a pair of
rugged source-to-source enhancement type DMOS transistors. Both integrated circuits are optically coupled to one light emitting diode,
which controls both switches. The output MOS transistors are protected with free-wheeling diodes that can handle up to 1.5A of inrush
current, making the relay ideal for switching lamps and highly inductive loads.
FEATURES
APPLICATIONS
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
High input-to-output isolation
Low input control power consumption
150mA maximum continuous load current
20 ohms maximum on-resistance
Long life/high reliability
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Telecom switching
Tip/Ring control
PCMCIA modules
Multiplexers
Meter reading systems
Data acquisition
Medical equipment
Battery monitoring
Home/Safety security systems
OPTIONS/SUFFIXES
MAXIMUM RATINGS
PARAMETER
Storage Temperature
Operating Temperature
8
7
6
5
鈥?/div>
鈥?/div>
-S
-TR
Surface Mount Option
Tape and Reel
UNIT
擄C
擄C
mA
mA
V
mW
MIN
-55
-40
TYP
MAX
125
85
40
400
SCHEMATIC DIAGRAM
+ Input
+ Input
- Input
1
2
3
4
+/- Output 1
Continuous Input Current
Transient Input Current
-/+ Output 1
+/- Output 2
-/+ Output 2
Reverse Input Control
Voltage
Output Power Dissipation
6
500
APPROVALS
鈥?/div>
鈥?/div>
鈥?/div>
BABT CERTIFICATE #607836:
BS EN 60950, BS EN 41003, BS EN 60065
CSA CERTIFICATE #LR111581-1
UL FILE #E90096
rev 1.0
Solid State Optronics, Inc.
1.888.377.4776
www.ssousa.com
