AD1885 Datasheet

  • AD1885

  • AC’97 SoundMAX Codec

  • 27頁

  • AD

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

a
AC鈥?7 2.1 FEATURES
Variable Sample Rate Audio
Multiple Codec Configuration Options
External Audio Power-Down Control
AC鈥?7 SoundMAX
廬
Codec
AD1885
ENHANCED FEATURES
Full Duplex Variable Sample Rates from 7040 Hz to
48 kHz with 1 Hz Resolution
Jack Sense Pins Provide Automatic Output Switching
Software-Enabled V
REFOUT
Output for Microphones and
External Power Amp
Split Power Supplies (3.3 V Digital/5 V Analog)
Mobile Low-Power Mixer Mode
Extended 6-Bit Master Volume Control
Extended 6-Bit Headphone Volume Control
Digital Audio Mixer Mode
PHAT鈩?Stereo 3D Stereo Enhancement
AC鈥?7 FEATURES
AC鈥?7 2.1-Compliant
Greater than 90 dB Dynamic Range
Stereo Headphone Amplifier
Multibit
Converter Architecture for Improved S/N
Ratio Greater than 90 dB
16-Bit Stereo Full-Duplex Codec
Four Analog Line-Level Stereo Inputs for:
LINE-IN, CD, VIDEO, and AUX
Two Analog Line-Level Mono Inputs for Speakerphone
and PC BEEP
Mono MIC Input w/Built-In 20 dB Preamp, Switchable
from Two External Sources
High Quality CD Input with Ground Sense
Stereo Line-Level Outputs
Mono Output for Speakerphone or Internal Speaker
Power Management Support
48-Terminal LQFP Package
FUNCTIONAL BLOCK DIAGRAM
ID0
ID1
JS0/EAPD
JS1
AD1885
CHIP SELECT
MIC1
MIC2
LINE
SELECTOR
JACK SENSES
AND EAPD CTRL
V
REF
V
REFOUT
0dB/
20dB
AUX
CD
VIDEO
PHONE_IN
PGA
16-BIT
A/D
CONVERTER
PGA
16-BIT
A/D
CONVERTER
RESET
SYNC
MONO_OUT
MMV
G
A
M
POP
PHAT
STEREO
NC
G
A
M
16-BIT
D/A
CONVERTER
G
A
M
G
A
M
G
A
M
G
A
M
G
A
M
AC LINK
SAMPLE
RATE
GENERATORS
BIT_CLK
HP_OUT_L
HV
SDATA_OUT
LINE_OUT_L
MV
SDATA_IN
LINE_OUT_R
MV
POP
PHAT
STEREO
G = GAIN
A = ATTENUATE
M = MUTE
MV = MASTER VOLUME
HV = HEADPHONE VOLUME
NC
A
M
G
A
M
16-BIT
D/A
CONVERTER
HP_OUT_R
HV
OSCILLATOR
PC_BEEP
XTL_OUT XTL_IN
SoundPort is a registered trademark and PHAT is a trademark of Analog Devices, Inc.
REV. 0
