ACU2110M1
CATV Upconverter Module
Advanced Product Information - Rev. 1
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Gilbert cell mixer including LNA.
Wideband VCO and LO buffer to mixer.
Internal varactor and resonator circuit.
Internal 1087.75 MHz first IF SAW filter
with differential input & output.
Shielded metal lid over a LCC
(7.6mm x 10.2mm).
APPLICATIONS
鈥?/div>
鈥?/div>
Cable Telephony
High Speed Cable Modems
M1
Shielded Metal lid over a LCC
7.6mm x 10.2mm 24 pin MCM Pkg.
DESCRIPTION
The ACU2110 is a CATV upconverter module, that when used with a synthesized downconverter, allows
integrating the tuner on the same PC board along with the rest of the electronics for data applications. These
applications included digital video, telephony, and cable modems. The module consists of a modified GaAs
upconverter, SAW filter, and varactor diode in a hermetic LCC package.
Electrical Characteristics (Temperature Range -40 to +85擄C)
Parameter
IF frequency
Supply voltage
Supply current
Noise figure to IF1
Conversion gain to IF1 (including filter)
AGC range
Crossmodulation ratio @ 15dBmV 15.75kHz square wave
Composite second order beat (15 dBmV 120 channels)
Composite triple beat (15 dBmV 120 channels)
Second order input intercept
Third order input intercept
Image rejection
Phase noise @ 1KHz
Phase noise @ 10KHz
Min
-
4.75
-
-
1
15
48
53
53
40
17
50
-
-
Typ
1087.75
5.00
-
-
-
-
-
-
-
-
-
-
-
-
Max
-
5.25
170
7
-
-
-
-
-
-
-
-
-48
-85
Units
MHz
V
mA
dB
dB
dB
dB c
dB c
dB c
dB m
dB m
dB
dBc/Hz
dBc/Hz
