ACS402 Datasheet

  • ACS402

  • QUAD AC LINE SWITCH ARRAY

  • 7頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
ACS402-5SB4
QUAD AC LINE SWITCH ARRAY
ASD鈩?/div>
AC Switch Family
s
s
MAIN APPLICATIONS
AC on-off static switching in appliance &
industrial control systems
Drive of low power high inductive or resistive
loads like:
- relay, valve, solenoid, dispenser
- pump, fan, micro-motor
- low power lamp bulb, door lock
FEATURES
4 high voltage AC switch array
Blocking voltage: V
DRM
/ V
RRM
= 500V
Clamping voltage: V
CL
= 600V
Nominal current: I
T(RMS)
= 0.2 A per switch
Nominal current: I
T(RMS
) = 0.4 A for the total
array
Switch integrated driver
Triggering current is sourced by the gate
Gate triggering current : I
GT
< 10 mA
s
s
s
s
s
s
s
s
DIP-20
PIN OUT CONNECTION
1
OUT1
G1
OUT2
G2
BENEFITS
Needs no external overvoltage protection.
Enables the equipment to meet IEC61000-4-5
standard.
Miniaturizes 4 switches in 1 package.
Reduces the switch component count by up to
80%.
Interfaces directly with the microcontroller.
Eliminates any stressing gate kick back on the
microcontroller.
s
s
s
s
s
s
OUT3
G3
OUT4
G4
COM
COM
note : pins 1, 3, 5, 7, 9, 12, 14, 16, 18, 20 not connected.
DESCRIPTION
The ACS402 belongs to the AC line switches array
family built around the ASD鈩?concept. This high
performance device includes 4 bi-directional a.c.
switches able to control an 0.2 A resistive or induc-
tive load device.
Each ACS鈩?switch integrates a high voltage
clamping structure to absorb the inductive turn off
energy and a gate level shifter driver to separate
the digital controller from each main switch. It is
triggered with a negative gate current flowing out
of the gate pin.
For further technical information, please refer to
AN1172 the Application note.
ASD and ACS are a trademarks of STMicroelectronics .
FUNCTIONAL DIAGRAM
OUT1
OUT2
OUT3
OUT4
ACS402
S1
S2
S3
S4
ON
ON
ON
ON
D1
D2
D3
D4
Com
G1
G2
G3
G4
October 2001 - Ed: 6B
1/8
