ACS240MS
March 1998
Radiation Hardened
Inverting, Octal, Three-State Buffer/Line Driver
Description
The Radiation Hardened ACS240MS is an Inverting, Octal,
Three-State Buffer/Line Driver with two active-LOW Enable
inputs (AE and BE). Each Enable input controls four outputs.
When an Enable input is LOW, the corresponding outputs
are active and input signals are inverted. A HIGH on an
Enable input causes the corresponding outputs to be high
impedance, regardless of the input levels.
The ACS240MS is fabricated on a CMOS Silicon on Sap-
phire (SOS) process, which provides an immunity to Single
Event Latch-up and the capability of highly reliable perfor-
mance in any radiation environment. These devices offer
signi鏗乧ant power reduction and faster performance when
compared to ALSTTL types.
Speci鏗乧ations for Rad Hard QML devices are controlled
by the Defense Supply Center in Columbus (DSCC). The
SMD numbers listed below must be used when ordering.
Detailed Electrical Speci鏗乧ations for the ACS240 are
contained in SMD 5962-98540. A 鈥渉ot-link鈥?is provided
on our homepage with instructions for downloading.
http://www.intersil.com/data/sm/index.htm
Features
鈥?QML Quali鏗乪d Per MIL-PRF-38535 Requirements
鈥?1.25Micron Radiation Hardened SOS CMOS
鈥?Radiation Environment
- Latch-up Free Under any Conditions
- Total Dose . . . . . . . . . . . . . . . . . . . . . . 3 x 10
5
RAD(Si)
- SEU Immunity . . . . . . . . . . . <1 x 10
-10
Errors/Bit/Day
- SEU LET Threshold . . . . . . . . . . . >100MeV/(mg/cm
2
)
鈥?Input Logic Levels V
IL
= (0.3V)(V
CC
), V
IH
= (0.7V)(V
CC
)
鈥?Output Current
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鹵16mA
鈥?Quiescent Supply Current. . . . . . . . . . . . . . . . . . . .20碌A(chǔ)
鈥?Propagation Delay . . . . . . . . . . . . . . . . . . . . . . . . 11.5ns
Applications
鈥?Databus Driving
鈥?Data Routing
鈥?Redundant Data Control Circuitry
Ordering Information
SMD PART NUMBER
5962F9854001VRC
N/A
5962F9854001VXC
N/A
N/A
INTERSIL PART NUMBER
ACS240DMSR-02
ACS240D/Sample-02
ACS240KMSR-02
ACS240K/Sample-02
ACS240HMSR-02
TEMP. RANGE (
o
C)
-55 to 125
25
-55 to 125
25
25
PACKAGE
20 Ld SBDIP
20 Ld SBDIP
20 Ld Flatpack
20 Ld Flatpack
Die
CASE OUTLINE
CDIP2-T20
CDIP2-T20
CDFP4-F20
CDFP4-F20
N/A
Pinouts
ACS240 (SBDIP)
TOP VIEW
AE
AI1
BO4
AI2
BO3
AI3
BO2
AI4
BO1
1
2
3
4
5
6
7
8
9
20 V
CC
19 BE
18 AO1
17 BI4
16 AO2
15 BI3
14 AO3
13 BI2
12 AO4
11 BI1
AE
AI1
BO4
AI2
BO3
AI3
BO2
AI4
BO1
GND
ACS240 (FLATPACK)
TOP VIEW
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
V
CC
BE
AO1
BI4
AO2
BI3
AO3
BI2
AO4
BI1
GND 10
