ADC601
12-Bit 900ns
ANALOG-TO-DIGITAL CONVERTER
FEATURES
q
q
q
q
FAST CONVERSION: 900ns
CAN BE SHORT-CYCLED
INPUT RANGES:
鹵
5V,
鹵
10V, 0 to 鈥?0V
HIGH SIGNAL/NOISE RATIO: 68dB
APPLICATIONS
q
DIGITAL SIGNAL PROCESSING
q
HIGH-SPEED DATA ACQUISITION
SYSTEMS
q
q
q
q
MEDICAL INSTRUMENTATION
ANALYTICAL INSTRUMENTATION
TEST AND IMAGING SYSTEMS
WAVEFORM ANALYZERS
q
LOW IMD: 75dB
q
PARALLEL AND SERIAL OUTPUT
q
32-PIN CERAMIC DIP PACKAGE
DESCRIPTION
The ADC601 is a high-speed Duolithic鈩?(two chips)
successive approximation analog-to-digital converter.
This unique two-chip design utilizes a bipolar technol-
ogy with on-chip thin film resistors to preserve analog
accuracy and a high-speed CMOS chip to perform
digital logic control. Outstanding linearity, noise, and
dynamic range are achieved by this converter design.
The ADC601 has been tested with several sample/hold
amplifiers and distortion results are documented in this
data sheet.
The ADC601 is complete with internal reference, clock,
and comparator and is packaged in a 32-pin ceramic
DIP. Conversion time is set at the factory to 900ns.
Serial and parallel output performance is guaranteed
with no missing codes over the full input voltage,
power supply, and operating temperature range. The
gain and offset errors are laser trimmed to specifica-
tion. Optionally they may be externally adjusted to
zero.
Internal scaling resistors are provided for the selection
of analog signal input ranges of
鹵5V, 鹵10V
and 0V to
鈥?0V. The ADC601鈥檚 input is specifically designed to
be easily driven with minimal disturbance to the driv-
ing amplifier.
Output codes are available in complementary binary
for unipolar inputs and bipolar offset binary for bipolar
inputs.
All digital inputs and outputs are TTL-compatible.
Power supply requirements are
鹵15V
and +5V.
Convert
Command
12-Bit
Successive Approx
Register (SAR)
鈥?/div>
+
Reference
Bipolar Offset
Input
Range Select
Comparator In
12-Bit D/A
Converter
Parallel
Digital
Output
Clock
Clock Rate Control
Clock Out
Status
Serial Out
Comparator
