AudioCoded
TM
Enabling Technology Products
AC481xx
Voice over Packet Processor
The highly featured, low cost and low power consumption
AC481xx
enables
the rapid development of medium density gateways, access devices and
routing/switching equipment, Residential Gateways and Integrated Access
Devices (IAD). With AudioCodes' field-proven, feature-rich software, the route
to the complete solution is fast and smooth.
Deliver Feature-Rich Solution
The AC481xx voice over packet processor combines up to five channels of
toll quality low bit rate voice compression, with a G.168-2000 compliant echo
canceller, and complete voice band processing functions in a single device.
With configurable tail length of up to 40 msec, the AC481xx delivers an
adaptive, state of the art echo canceller. Field-proven G3 Fax Relay, compliant
with the T.38 ASN.1 standard, is a major enhancement to the AC481xx offering.
Other advanced features include dynamic packet size programming, high
quality DTMF/MF R1/MF R2/Call Progress Tones, detection and generation
of user defined tones and Caller ID, Silence Suppression and automatic
Voice/Fax/Data discriminator.
Fast Integration with Software Stacks
樓
樓
樓
樓
Independent multi-channel operation
Toll quality voice compression
Robust bandwidth-saving fax relay
Field-proven reference designs
樓
Low per-channel cost and power
樓
Proprietary evaluation &development tools
The AC481xx is supported by the VoicePacketizer
TM
software stack which
enables the processor to create a VoIP-compliant media stream as part of a
Media Gateway entity. The VoicePacketizer么 is an ANSI-C software stack that
supports the RTP/RTCP protocol. The software stack also provides a simple
API for initialization and configuration of the AC481xx and for run-time call
control. The VoicePacketizer
TM
enables easy control of the packet processor
and fast time-to-market.
Software Upgrades
The complete functionality of the multi-channel processor is implemented in
the internal firmware, which is downloaded into the processor by the host
prior to start of the operation. This allows the addition of new features in
future product releases without system hardware modifications.
Benefit From Extensive Experience
AudioCodes is one of the world's leading providers of DSP solutions since
1996. During this period, the company successfully passed numerous
interoperability tests, while maintaining high levels of performance. AudioCodes'
commitment to innovation yields consistently high-quality voice processing
products that are feature-rich and field-proven. AudioCodes has deployed
more than 5 million VoP ports to date.
AC481xx Features
7
7
7
7
7
7
Wireline & wireless low bit rate Vocoders
Low power consumption & small footprint
G.168-2000 compliant Echo Canceller
T.38 compliant Fax Relay
Complete Voice Band Signaling support
Caller ID support
