APPLICATION BULLETIN
Mailing Address: PO Box 11400 鈥?Tucson, AZ 85734 鈥?Street Address: 6730 S. Tucson Blvd. 鈥?Tucson, AZ 85706
Tel: (602) 746-1111 鈥?Twx: 910-952-111 鈥?Telex: 066-6491 鈥?FAX (602) 889-1510 鈥?Immediate Product Info: (800) 548-6132
BUILD A THREE PHASE SINE WAVE GENERATOR
WITH THE UAF42
By Johnnie Molina (602) 746-7592
Figure 1 shows how a three phase sine wave oscillator can
be built using one UAF42 state variable filter along with
some resistors and diodes. Three output nodes are available;
highpass out, bandpass out and lowpass out. The signal at
the bandpass and lowpass out nodes are 90擄 and 180擄 out of
phase, respectively, with the highpass out node. An on-chip
auxiliary op amp is available for use as a buffer or gain
stage.
SETTING THE FREQUENCY OF OSCILLATION
The frequency of oscillation is set with resistors R
F1
and R
F2
using Equation 1.
f
OSC
=
Where,
1
2
蟺
RC
(1)
R = R
F1
= R
F2
C = C
1
= C
2
= 1000pF
The max f
OSC
obtainable using the UAF42 state variable
filter is 100kHz. Distortion becomes a factor though for
frequencies above 10kHz. For low frequencies of oscillation
(f
OSC
< 100Hz), the use of external capacitors is recom-
mended. They should be placed in parallel with the inter-
nally supplied C
1
and C
2
capacitors. This will reduce the
V+
R
1
A sin(蠅t)
Highpass
Out
R
F1
R
FB
12
13
8
50k鈩?/div>
UAF42
C
1
1000pF
C
2
1000pF
Auxiliary
Amp
7
C
EXT(1)
1N914
A sin(蠅t + 90擄)
Bandpass
Out
R
F2
A sin(蠅t + 180擄)
Lowpass Out
C
EXT(1)
5
14
1
R
2
50k鈩?/div>
6
50k鈩?/div>
2
3
50k鈩?/div>
8
1N914
7
R
4
9
V鈥?/div>
10
V+
11
4
R
3
NOTE: (1) C
EXT
is required for f
OSC
鈮?/div>
100Hz鈥攕ee text.
V鈥?/div>
FIGURE 1. Three Phase Quadrature Oscillator.
漏
1994 Burr-Brown Corporation
AB-096
1
Printed in U.S.A. July, 1994
