APPLICATION BULLETIN
Mailing Address: PO Box 11400 鈥?Tucson, AZ 85734 鈥?Street Address: 6730 S. Tucson Blvd. 鈥?Tucson, AZ 85706
Tel: (602) 746-1111 鈥?Twx: 910-952-111 鈥?Telex: 066-6491 鈥?FAX (602) 889-1510 鈥?Immediate Product Info: (800) 548-6132
DIGITALLY PROGRAMMABLE, TIME-CONTINUOUS
ACTIVE FILTER
by Johnnie Molina, (602) 746-7592
Programmable active filters have increased in popularity
over the past decade. With the advent of switched capacitor
topologies, filter parameters such as the natural frequency
and filter Q can be changed simply by varying the clock
frequency. But switched capacitor filters are sampled data
systems and are subject to anomalies such as clock
feedthrough noise and aliasing errors.
The circuit in Figure 1 shows how an analog, digitally
programmable filter can be built using a UAF42. This
monolithic, state-variable active filter chip provides a two
pole filter building block with low sensitivity to external
component variations. It eliminates aliasing errors and clock
feedthrough noise common to switched capacitor filters.
Lowpass, highpass, bandpass and notch (band reject) out-
puts are available simultaneously.
Digital
Word
In
Pins
4
17
15
18
D
1
- D
12
Pins
4
OPA627
17
15
18
OPA627
DAC7541A
2
1
DAC7541A
2
1
R
F1
13k鈩?/div>
R
F2
13k鈩?/div>
10k鈩?/div>
R
Q
35.4k鈩?/div>
13
8
50k鈩?/div>
7
14
1
UAF42
10k鈩?/div>
5
10k鈩?/div>
R
G
49.9k鈩?/div>
In
12
50k鈩?/div>
C
1
1000pF
C
2
1000pF
Aux Amp
Out
6
50k鈩?/div>
(NC)
2
50k鈩?/div>
3
(13)
9
V鈥?/div>
10
V+
(7)
11
(1)
4
High-Pass
Out
Band-Pass
Out
Low-Pass
Out
Notch
Out
FIGURE 1. Digitally Programmable Analog Filter.
漏
1994 Burr-Brown Corporation
AB-062
Printed in U.S.A. February, 1994
