EXTENDING THE COMMON-MODE RANGE
OF DIFFERENCE AMPLIFIERS
By R. Mark Stitt (602) 746-7445
Extending the common-mode range of difference amplifiers
allows their use in a wider variety of reduced power-supply
applications.
The INA117 has a specified common-mode input range of
鹵200V
when operating on standard
鹵15V
power supplies. At
power-supply voltages above
鹵13V,
the INA117 input range
is limited to
鹵200V
by the power capabilities of its internal
input resistors. On reduced power supplies, the input range
is limited by the common mode input range of the internal
op amp.
The linear common-mode input range of the internal op amp
extends to within 3V of its power supply voltage. For
example, with a
鹵15V
power supply, the common-mode
input range of the internal op amp is
鹵12V.
Because the
INA117 internal resistor network divides the input by 20, the
actual input range of the INA117 would be 20 鈥?(鹵12V), or
240V, for
鹵15V
power supplies. Similarly, reducing the
power supply voltage to
鹵6V
will limit the input common-
mode voltage to
鹵60V.
There are two approaches to boosting the common-mode
input range for reduced power supply applications: Offset-
ting the common-mode range by a fixed amount, and dy-
namically adjusting the common-mode range to follow the
input common-mode signal.
OFFSETTING THE INPUT COMMON-MODE
RANGE WITH A CONSTANT VOLTAGE
In many applications, the common-mode signal range is
known and the common-mode input range of the difference
amplifier can be adjusted to coincide with the required
range. For example, the
鹵60V
common-mode range of the
INA117 operating on
鹵6V
supplies could be shifted to range
from +0V to +120V, or +50V to +170V.
To offset the common-mode range, the reference connection
of the difference amplifier is connected to an offsetting
voltage, V
X
, instead of ground. With the reference connected
to an offsetting potential, a second difference amplifier must
be used to refer the output back to ground.
One way to offset the input voltage is to connect the
reference pins 1 and 5 to the negative supply voltage as
shown in Figure 1. Another possibility is to derive the offset
voltage from a zener diode connected to the negative power
supply as shown in Figure 2. In either case, the total
common-mode range of the INA117 is unchanged and
shifted by 鈥?9 鈥?(V
X
).
V+
7
R
1
380k鈩?/div>
R
2
380k鈩?/div>
7
R
3
380k鈩?/div>
R
1
25k鈩?/div>
R
2
25k鈩?/div>
V
2
2
6
2
5
V
3
3
R
5
21.1k鈩?/div>
8
1
5
R
4
20k鈩?/div>
4
6
A
1
INA117
3
R
3
25k鈩?/div>
A
2
R
4
25k鈩?/div>
INA105
1
V
O
= V
3
鈥?V
2
鈥?V > V
O
> 鈥?0V
Swap A
2
pins 2 and 3 for:
10V > V
O
> 3V
also;
((V+) 鈥?5V) > V
O
> ((V鈥? + 3V)
V鈥?/div>
4
V
X
= V鈥?/div>
FIGURE 1. Offsetting the INA117 Common-Mode Input Range Using the Negative Power Supply as a Reference.
漏
1990 Burr-Brown Corporation
AB-015
AB-015
Printed in U.S.A. August, 1990
