18鈥?3 GHz Power Amplifier
AA022P1-65
Features
I
15 dB Gain
I
+24 dBm Output Power
I
Hermetic Package with Solderable Leads
I
Single Voltage Operation
I
100% RF and DC Testing
Description
The AA022P1-65 is a broadband millimeterwave amplifier
in a hermetic package. The amplifier is designed for use
in millimeterwave communication and sensor systems as
the transmitter front-end, transmitter gain stage, or local
oscillator gain stage when high gain and high power are
required. The solder-sealed hermetic package provides
excellent electrical performance, excellent thermal
performance, and complete environmental protection for
long-term reliability. A single supply voltage simplifies bias
requirements. All amplifiers are screened at the operating
frequencies prior to shipment for guaranteed
performance. The amplifier is targeted for millimeterwave
point-to-point
and
point-to-multipoint
wireless
communications systems.
Pin Out
N/C
N/C
AA022P1-65
RF In
RF In
RF Out
RF Out
YYWW
V
DD
V
D
Electrical Specifications at 25擄C (V
D
= 5.5 V)
RF
Parameter
Bandwidth
Small Signal Gain
Input Return Loss
Output Return Loss
Output Power at Saturation
Output Power at 1 dB Gain Compression
Temperature Coefficient of Gain
Symbol
BW
G
RL
I
RL
O
P
SAT
P
1 dB
dG/dT
22
Min.
18
13
Typ.
17鈥?4
15
9
9
25
24
-0.019
Max.
23
Unit
GHz
dB
dB
dB
dBm
dBm
dB/C
DC
Parameter
Drain Current (Small Signal)
Drain Current (At Saturation)
Symbol
I
D
I
D-SAT
Min.
260
Typ.
360
325
Max.
420
Unit
mA
mA
Alpha Industries, Inc.
[781] 935-5150
鈥?/div>
Fax
[617] 824-4579
鈥?/div>
Email
sales@alphaind.com
鈥?/div>
www.alphaind.com
Specifications subject to change without notice. 2/00A
1
1
2
3
4
