G
AS
D
ISCHARGE
T
UBE
8x6mm
No. A930/A931/A932
Littelfuse series SL1011B.
2-electrode (10kA/10A)
Medium Discharge
Current Series
This product is not recommended
Features
for new designs. Please refer to
Non-radioactive
Applications
Telecommunication
Data Transmission
Trigger Circuits
Power Line Modules
Lead Free
A930 can be used in holder No. 706
Specifications
Packaging
A930:
A931:
A932:
Materials
Housing:
Gas:
Leads:
~ 15V
00=Bulk (1.000 pcs.)
01=Reel (500 pcs.)
02=Blister Tape (600 pcs.)
Ceramic
non-radioactive
tin plated
Arc Voltage @ 1A
Transition Glow to Arc @
~ 0.8A
Standard
UL-497B
complies to ITU-T K.12 (formerly CCITT)
complies to DIN 57845/VDE 0845
UL-recognized
Operating temperature
-40擄C to +90擄C
Climatic Category
complies to IEC 60068-1
+40擄C, 21 days, <93% humidity
Soldering characteristics
complies to IEC 60068-2-20 (A931)
Soldering Heat Resistance
complies to IEC 60068-2-58
Marking
, Type, Nom. Voltage, Date
Unit Weight
ca. 1.5g
Approvals
WebLinks
Further info see:
http://www.wickmanngroup.com/
download/orderinfo_surgearr.pdf
http://www.wickmanngroup.com/
download/crossref_surgearr.pdf
Characteristics
Type/
Order Code
DC
Tolerance Impulse
sparkover
sparkover
voltage
voltage
(1kV/碌s)
typ.
Glow
Insulation Capacitance
8/20碌s
8/20碌s
AC
AC
Approval
Voltage Resistance
(@1MHZ)
Nominal
Single
Nominal Alternating
(@100 Vdc or
Impulse
Impulse Discharge Discharge
@50Vdc for 90V)
Discharge Discharge Current
Current
Current
Current
(50Hz; 1s;
(50Hz;
(10 times)
(1 time)
(10 times) 9 cycles)
UL-rec.
~ 60V
> 10G鈩?/div>
< 1.5 pF
10kA
12kA
10A
65A
鈥?/div>
A930 S0 0090 01 00
A931 S0 0090 01 01
A932 S0 0090 01 02
90V
+/- 20%
<550V
A930 S0 0230 01 00
A931 S0 0230 01 01 230V
A932 S0 0230 01 02
A930 S0 0350 01 00
A931 S0 0350 01 01 350V
A932 S0 0350 01 02
A930 S0 0600 04 00
A931 S0 0600 04 01 600V
other values on request
Specifications are subject
to change without notice.
+/- 20%
<600V
~ 60V
> 10G鈩?/div>
< 1.5 pF
10kA
12kA
10A
65A
鈥?/div>
+/- 20%
<800V
~ 60V
> 10G鈩?/div>
< 1.5 pF
10kA
12kA
10A
65A
鈥?/div>
-10/+20%
<1.100V
~ 60V
> 10G鈩?/div>
< 1.5 pF
10kA
12kA
10A
65A
鈥?/div>
Order
Example
Qty.
Order-
Number
Type
A930
Failsafe Option Sparkover Volt.
S0
0090
Tolerance
01
Packaging
00
050915
WebSite
Europe
Tel: +49 2302 662-107
www.wickmanngroup.com E-mail: sales@wickmann.com
Americas
Tel: +1 404 699-7820
E-mail: service@wickmannusa.com
Asia
Tel: +852 26 14-1108
E-mail: sales@wickmann.com.hk
China
Tel: +86 21 6432 5146
E-mail: sales@wickmann.cn
