GIGABIT DUAL

TRANSFORMERS

For Use with 150

鈩?/div>

Twinax Cable

Compliant with ANSI X3T9.5, FC-PH-3 Fibre

Channel Physical Layer Specification

Compliant with IEEE 802.3z PMD

Designed for fast rise-time and a low frequency

cutoff of 2.5 MHz

IC grade transfer-molded package withstands

235擄C peak temperature profile

Electrical Specifications @ 25擄C 鈥?Operating Temperature 0擄C to 70擄C

Part

Number

A6801

A6802

Turns Ratio

(鹵6%)

1CT:1CT

1:1

Primary Inductance

OCL (碌H MIN)

(@ 20 mVrms, 100

kHz)

5.50

DCR

(鈩?MAX)

0.21

Hi-Pot

(Vrms)

1500

Rise Time

(ps MAX)

20-80%

350

280

Low Frequency

Cutoff

(-3 dB)

< 2.5 MHZ

Mechanical

A680X

.090

2,29

.500 鹵.010

12,70 0,25

.460 .280

11,68 7,11

.420 .295

10,67 7,49

.350

8,89

.050

1,27

Schematics

A6801

1:1

A680X

Date Code Cntry of Origin

.030

0,76

SUGGESTED PAD LAYOUT

.018

X 16

0,46

A6802

.220 鹵.010

5,59 0,25

.050

1,27

.350

8,89

.004/0,10

16 SURFACES

1:1

0鈥?擄

.020

MIN

0,51

.005 .015

鈥?/div>

0,13 0,38

1:1

Dimensions:

Inches

Unless otherwise specified, all tolerances are 鹵 .005

0,13

Weight

. . . . . . . . . . . .1.4 grams

Tape & Reel

. . . . . . . . .500/reel

Tube

. . . . . . . . . . . . . . .45/tube

NOTE:

For lower speed Fibre Channel applications, please refer to application note on data sheet A101.

U.S.A:

TEL 619 674 8100

鈥?/div>

EUROPE:

TEL 441 483 401 700

鈥?/div>

ASIA:

TEL 886 7 821 3141

鈥?/div>

WEB:

http://www.pulseeng.com

A100.A (1/99)

制造商
Pulse
產品種類
變壓器音頻和信號
頻率范圍
2.5 MHz
絕緣電壓
1.5 kV
工作溫度范圍
0 C to + 70 C
端接類型
Pin
尺寸
12.7 mm L x 7.49 mm W x 10.67 mm H
產品
Signal Transformers
電流額定值
8 mA
封裝 / 箱體
SOIC-16
屏蔽
Unshielded
工廠包裝數量
35
類型
Gigabit Dual Transformer
