Back

Emergency Stop Switch

Mounting Aperture of 16 mm

Modular construction, easy installation

Positive opening mechanism with minimum contact

separation of 3 mm in accordance with

EN60947-5-1,

鈫?/div>

Conforms to EN418

Includes a safety lock to prevent malfunction

Features the separate construction that allows the

Switch Unit to be separated for improving wiring

efficiency and the one-piece-like construction that

allows easier handling.

UL and CSA approved, VDE (pending)

High reliability, IP65

Short mounting depth, less than 28.5 mm below

panel

Quick and easy assembly, snap-in Switch Unit.

A165E is identifiable, clearly visible and will stop a

dangerous process, without creating additional

hazards.

A165E

Ordering Information

Construction

Illumination Colors

鈥?/div>

Protective Structure and Terminal Type

LED Illumination

Red

Non-lighted

Red

鈥?/div>

Protective Structure

Oil-resistant IP65

Terminal Type

Solder terminals

(tab terminals #110)

Lamp

Illumination Method

LED

鈥?/div>

LED

Switch Unit Specifications

鈥?/div>

General-purpose Loads

125 VAC: 5 A

250 VAC: 3 A

30 VDC

Note:

A165E Emergency Stop Switch must be ordered as a set.

No LED is installed for the non-lighted model.
