Proximity Sensors
18 mm Diameter Stainless Steel Impact Sensors
3-Wire DC, 2-Wire AC Type
FEATURES
Spring loaded sleeve absorbs shock on
impact
E-ring grooves allow adjustable switch
travel from 0.25 to 1.00 inch
Stainless steel housing and sensing
face
Designed to meet NEMA 4X, 6P, 13
ORDER GUIDE
Sensor
Package
Style
18 mm (.71 in.)
Sensing
Range
mm (in.)*
1,65 (.065)
Shielded
1,65 (.065)
Shielded
Sensor
Type
3-wire
DC
2-wire
AC
Sw.
Freq.
20 Hz
20 Hz
Standard
Target*
mm (in.)
18 (.71)
18 (.71)
Output
Type
973SPT Series
Detects ferrous metals only
Quick-connect termination
93-132 VAC and 10-30 VDC supply
voltages
Short circuit protection on DC sensors
18 mm diameter threaded sleeve for
mounting flexibility
LED
NO
NO
Catalog
Listing
972SPT-A3P
973SPT-A5T
PNP, N.O.
N.O.
136g (4.8 oz)
*Ferrous metals only.
SPECIFICATIONS
Supply Voltage
Voltage Drop
Load Current
Leakage Current
Repeatability
Operating Frequency, max.
Hysteresis
Operating Temperature
LED
Protection
Spring Actuation Force
Initial impact
Full spring travel
AC
93-132 VAC
7.5 V @ 100 mA
5-100 mA cont.
500 mA inrush
1.7 mA max.
鹵
1%
20 Hz
2 to 20% of sensing distance
0 to 70
擄C
(32 to 162
擄F)
None
NEMA 4, 4X, 6P, 13
1/4 pound
1/2 pound
DC
10-30 VDC
1.0 V
200 mA max.
10
碌A(chǔ)
max.
鹵
1%
20 Hz
None
ACCESSORIES
Catalog Listing*
925SST18
A803000A09M020
803000A09M050
803001A09M020
803001A09M050
8030P1A09M020
8030P1A09M050
703000D02F060
703000D02F120
703001D02F060
703001D02F120
Description
Jam nut accessory
4-pin DC Micro standard key, straight, 2m cable
4-pin DC Micro standard key, straight, 5m cable
4-pin DC Micro standard key, right angle, 2m cable
4-pin DC Micro standard key, right angle, 5m cable
4-pin DC Micro standard key, right angle w/LED, 2m cable
4-pin DC Micro standard key, right angle w/LED, 5m cable
3-pin AC Micro dual slot, straight, 2m cable
3-pin AC Micro dual slot, straight, 4m cable
3-pin AC Micro dual slot, right angle, 2m cable
3-pin AC Micro dual slot, right angle, 4m cable
JAM NUT
In some applications, there can be a great
deal of impact force between target and
sensor. Thus, it may be necessary to protect
the threaded sleeve from damage. Sleeve
damage could cause the sensor to bind
within the sleeve, affecting sensor perform-
ance. A specially designed jam nut which
screws onto the end of the 18 mm sleeve
provides the required protection.
*High temperature/thermal cycle washdowns may cause loosening of cables to sensor, due to material
incompatibility. Stainless steel or plastic cable nuts are suggested in these applications.
