256 Kbytes on-chip flash program memory
40 MHz operation
Optional clock quadrupler
Programmable clock output signal
(CLKOUT)
2 Mbytes of linear address space
1.25 Kbytes of register RAM
2.75 Kbytes of code RAM
Register-to-register architecture
Stack overflow/underflow monitor with
user-defined upper and lower stack pointer
boundary limits
Two peripheral interrupt handlers (PIHs)
provide direct hardware handling of up to 45
interrupts
Up to 59 I/O port pins
Full-duplex serial port with dedicated
baud-rate generator
Enhanced synchronous serial I/O unit
(SSIO)
16 10-bit A/D channels with auto-scan
mode and dedicated results registers
Controller area network (CAN) 2.0
networking protocol
Serial debug unit provides read and write
access to code RAM with no CPU overhead
鈥?/div>
Chip-select unit (CSU)
鈥?Three chip-select pins
鈥?Dynamic demultiplexed/multiplexed
address/data bus for each chip-select
鈥?Programmable wait states
(0, 1, 2, or 3) for each chip-select
鈥?Programmable bus width (8- or 16-bit)
for each chip-select
鈥?Programmable address range for each
chip-select
鈥?/div>
Event processor array (EPA)
鈥?Two flexible 16-bit timer/counters
鈥?Five high-speed capture/compare
channels with a lock feature for noise
filtering
鈥?10 enhanced high-speed
capture/compare channels with period
and duty cycle measurement capability,
as well as a lock feature for noise
filtering
鈥?/div>
鈥?/div>
Complete system development support
Packaging
鈥?132-pin PQFP
鈥?/div>
Temperature Offerings
鈥?Commercial (0C - 70C)
鈥?Extended (-40C - 85C)
The Intel
廬
88CO196EC CHMOS 16-Bit Microcontroller is the first member of
the MCS
廬
96 family of microcontrollers to integrate flash memory on-chip. The
Intel廬 88CO196EC, with its integrated flash memory, brings a new level of
integration that offers embedded system designers cost-effective solutions.
Order Number:
273970-002
August,
2004
