TSOP11..KA1
Vishay Semiconductors
IR Receiver Modules for Remote Control Systems
Description
The TSOP11..KA1 - series are miniaturized receivers
for infrared remote control systems. PIN diode and
preamplifier are assembled on lead frame, the epoxy
package is designed as IR filter.
The demodulated output signal can directly be
decoded by a microprocessor. The main benefit is the
operation with short burst transmission codes and
high data rates.
12797
Features
鈥?Photo detector and preamplifier in one package
鈥?Internal filter for PCM frequency
鈥?Improved shielding against electrical field distur-
bance
鈥?TTL and CMOS compatibility
鈥?Output active low
鈥?Low power consumption
鈥?High immunity against ambient light
Parts Table
Part
TSOP1130KA1
TSOP1133KA1
TSOP1136KA1
TSOP1137KA1
TSOP1138KA1
TSOP1140KA1
TSOP1156KA1
30 kHz
33 kHz
36 kHz
36.7 kHz
38 kHz
40 kHz
56 kHz
Carrier Frequency
Special Features
鈥?Enhanced data rate up to 4000 bit/s
鈥?Operation with short bursts possible (鈮?6 cycles/
burst)
Application Circuit
Transmitter
TSOPxxxx
with
TSALxxxx
Circuit
R
1
= 100
鈩?/div>
V
S
C
1
=
4.7 碌F
V
O
+V
S
Block Diagram
2
25 k鈩?/div>
Input
PIN
AGC
Band
Pass
Demo-
dulator
V
S
OUT
GND
碌C
GND
3
OUT
R
1
+ C
1
recommended to suppress power supply
disturbances.
The output voltage should not be hold continuously at
a voltage below V
O =
3.3 V by the external circuit.
1
Control Circuit
GND
Document Number 82007
Rev. 9, 15-Oct-2002
www.vishay.com
1
